4 Pole Auxiliary Contact Module | 3 N/O & 1 N/C Contacts | IP20 Protection | Eaton
The DILA-XHI31 is a 4 pole auxiliary contact module featuring 3 normally open and 1 normally closed contacts—ideal for industrial control panels and automation systems. Built for reliable performance, it offers a high mechanical lifespan of up to 10 million operations and IP20 protection for safe operation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 4 Pole Auxiliary Contact Module | 3 N/O & 1 N/C Contacts | IP20 Protection | Eaton
Brand: Eaton
SKU: Y7-276427
Alternatively Known As: DILA Auxiliary Contact Module, Eaton DILA-XHI31, 4 Pole Auxiliary Contact Block, DILM Auxiliary Contact Module
Technical Specifications
- Number of poles: 4
- Contact configuration: 3 Normally Open (N/O), 1 Normally Closed (N/C)
- Rated thermal current (Ith): 16 A
- Rated operational current (Ie) AC-15: 4 A at 220-240 V
- Rated operational current (Ie) DC: varies by voltage, e.g., 0.5 A at 110 V DC
- Rated insulation voltage (Ui): 690 V
- Rated operational voltage (Ue) max AC: 500 V
- Degree of protection: IP20
- Shock resistance: 5 g to 7 g half-sinusoidal shock
- Operating temperature range: -25 °C to 60 °C
- Mounting method: Front fastening
- Connection type: Screw terminals
- Mechanical lifespan: 10,000,000 operations
- Electrical lifespan: 1,300,000 operations at 230 V AC-15, 3 A
- Overvoltage category: III
- Pollution degree: 3
- Rated impulse withstand voltage (Uimp): 6000 V AC
- Dimensions (H x L x W): 38mm x 45mm x 36mm
- Weight: 0.048 kg
Key Features
- 4 pole auxiliary contact module with 3 normally open and 1 normally closed contacts
- Interlocked opposing contacts according to IEC 60947-5-1 Annex L
- Front mounting with screw terminals for secure connection
- High mechanical and electrical lifespan with up to 10,000,000 mechanical operations
- Rated operational current up to 4 A at AC-15 and 0.5 A at DC voltages
- Protection degree IP20 with finger and back-of-hand protection
- Shock resistance up to 7 g half-sinusoidal shock
- Operating temperature range from -25 °C to 60 °C
Professional Installation Requirements
- Installation should be performed by a qualified electrician or technician familiar with industrial control equipment and electrical safety standards.
Applications
- Industrial control panels
- Electrical switchgear assemblies
- Automation systems requiring auxiliary contact modules
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable design reduces need for frequent replacements, minimizing waste
- Complies with international standards ensuring safe and efficient operation
Warranty Information
Standard Eaton warranty applies; please refer to Eaton's official warranty policy for details.
Available Now
The Eaton Moeller DILA-XHI31 Auxiliary Contact Module is available for immediate purchase, ideal for industrial and automation control panel applications.
