4 Pole Contactor | 25A AC-3 Rated | Compact DIN Rail Mount | by Clipsal
The 4 Pole Contactor is designed for versatile switching applications, rated for motor control up to 25A at 400V. With a compact DIN rail mount design, it's perfect for industrial motor control, lighting circuits, and HVAC systems. Built for reliability, it ensures efficient energy management and safe operation in automation systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 4 Pole Contactor | 25A AC-3 Rated | Compact DIN Rail Mount | by Clipsal
Brand: Clipsal
SKU: SCHLC1D258U7
Alternatively Known As: 4 Pole Contactor, 4P Contactor, Industrial Contactor, Motor Contactor, SCHLC1D258U7
Technical Specifications
- Number of Poles: 4
- Rated Operational Current (AC-3): 25A at 400V
- Control Voltage: 220-240V AC 50/60Hz
- Mounting: DIN rail
- Auxiliary Contacts: None (main contacts only)
- Mechanical Life: 10 million operations
- Electrical Life: 1 million operations (AC-3)
- Operating Temperature: -5°C to +60°C
- Standards: IEC 60947-4-1
- Dimensions (H x L x W): 85mm x 100mm x 45mm
- Weight: 0.6 kg
Key Features
- 4 pole contactor for versatile switching applications
- AC-3 rated for motor control up to 25A at 400V
- Compact DIN rail mount design
- Reliable electromagnetic operation
- Suitable for both resistive and inductive loads
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local electrical regulations.
Applications
- Industrial motor control
- Lighting circuits
- HVAC systems
- Power distribution panels
- Automation systems
Standards & Compliance
- Complies with AS/NZS 60947 for low-voltage switchgear and controlgear
Environmental Benefits
- Enables efficient energy management in automation systems
- Supports safe and reliable switching to reduce energy waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal SCHND 4 Pole Contactor SCHLC1D258U7 is available for immediate purchase. Ideal for industrial and commercial power switching and automation applications.
