PES 660V 60A 4P Gland Bracket (270) 25-C 38-41-G (241.1)

4 Pole Gland Bracket 660V 60A | IP55 Rated | Stainless Steel | Ausproof

BRAND: Ausproof

SKU: RS2283

$2,190.40 List price: $2,720.40

+ −

30 Days Return Delivery Options

4 pole gland bracket with 660V operating voltage and 60A current rating—ideal for mining and hazardous environments. Built for durability with IP55 ingress protection and stainless steel construction, ensuring reliable performance in tough conditions.

Description

Product Name/Title: PES 660V 60A 4P Gland Bracket (270) 25-C 38-41-G (241.1)

Brand: Ausproof

SKU: RS2283

Alternatively Known As: PES 60A Gland Bracket, Ex-rated Gland Bracket, 4 Pole Gland Bracket, Flameproof Gland Bracket

Technical Specifications

Operating Voltage: 660-1,100V
Current Rating: 60A Ex, 90A Non-Ex
Material: Grade 304 Stainless Steel
Ingress Protection: IP55
Through Fault Current (Phase): 3.2kA for 0.2 seconds (2 tests)
Through Fault Current (Earth): 1.0kA for 0.2 seconds (2 tests)
AC HV Withstand (Phase): 4.2kV for one minute
AC HV Withstand (Pilot): 1.0kV for one minute
Temperature Rise: Suitable for 60A and 90A
Compliant to: AS/NZS 1299, IEC 60079-0, IEC 60079-1
Dimensions (H x L x W): 150mm x 200mm x 250mm
Weight: 5 kg

Key Features

A single solid earth body
Single piece contacts to prevent hot joints
Easy termination
Easy flameproof repair
Full solid earth connectivity throughout product
Full phase to phase segregation with earth
Lightest Ex product on the market
Silicone protection cover
Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles

Professional Installation Requirements

Installation should be performed by qualified personnel familiar with Ex-rated electrical equipment and hazardous area requirements.

Applications

Mining
Tunnelling
Commercial applications
Group 1 hazardous environments

Standards & Compliance

Complies with AS/NZS 1299 for plugs and socket-outlets

Environmental Benefits

Durable stainless steel construction reduces need for frequent replacements.
Flameproof repairability reduces waste by allowing on-site barrel replacement.

Warranty Information

Standard manufacturer warranty applies. Please contact Ausproof for detailed warranty terms.

Available Now

The Ausproof PES 660V 60A 4P Gland Bracket is available now for immediate purchase. Ideal for mining, tunnelling, and hazardous commercial applications.
