400A Type J Fuse | 415V AC | 80 kA Breaking Capacity | gG/gL Class by Eaton
400A Type J fuse with a 415V AC rating and 80 kA breaking capacity—ideal for low voltage electrical protection in industrial and commercial systems. Built for reliable circuit protection, with slotted tags for easy installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 400A Type J Fuse | 415V AC | 80 kA Breaking Capacity | gG/gL Class by Eaton
Brand: Eaton
SKU: 400PJ31-7
Alternatively Known As: 400A Type J Fuse, 415V AC Fuse, BS88/J Fuse, Low Voltage Fuse, Eaton PJ31 Fuse
Technical Specifications
- Amperage Rating: 400 A
- Voltage Rating: 415 V AC
- Breaking Capacity: 80 kA
- Class: gG/gL
- Fuse Type: PJ31
- Construction: BS88/J
- Fitted with: Slotted tags
- Certifications: BS IEC 60269, CE Marked, RoHS Compliant
- Dimensions (H x L x W): 38mm x 131mm x 38mm
- Weight: 0.3 kg
Key Features
- 400A amperage rating suitable for high current applications
- 415V AC voltage rating
- Breaking capacity of 80 kA for high fault current interruption
- Class gG/gL fuse type for general purpose protection
- Slotted tags for easy installation and secure connection
- Complies with BS IEC 60269 and CE Marked RoHS compliant
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with safety standards and proper fuse selection.
Applications
- Low voltage electrical protection in industrial and commercial electrical systems
- Protection of electrical circuits in switchboards and distribution panels
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- RoHS compliant ensuring reduced hazardous substances
- Durable construction reduces waste through long service life
Warranty Information
Standard manufacturer warranty applies. Please refer to Eaton's warranty policy for details.
Available Now
The Eaton Bussmann Series 400AMP 415V AC Type J Fuse is available for immediate purchase, ideal for industrial and commercial electrical protection applications.
