4K2K HDMI & VGA HDBaseT Extender | 2 HDMI Inputs | 100m Transmission | by SERVEREDGE
The 4K2K HDMI & VGA HDBaseT Extender is designed for high-definition video transmission, featuring 2 HDMI inputs and 1 VGA input for versatile connectivity. Ideal for corporate, educational, and entertainment applications, it supports up to 100 meters of transmission over a single Cat5e/6 cable, making it perfect for professional AV installations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 4K2K HDMI & VGA HDBaseT Extender | 2 HDMI Inputs | 100m Transmission | by SERVEREDGE
Brand: SERVEREDGE
SKU: HD2V-EX-100-HDBT
Alternatively Known As: HDBaseT Extender, HDMI VGA Extender, 4K HDMI Extender
Technical Specifications
- Video Inputs: 2 x HDMI, 1 x VGA
- Video Output: HDBaseT
- Maximum Resolution: 4K2K (3840x2160)
- Transmission Distance: Up to 100 meters over Cat5e/6 cable
- Power Supply: External 12V DC adapter
- HDBaseT Standard: Supports video, audio, and control signals
- Dimensions (H x L x W): 45mm x 150mm x 210mm
- Weight: 1.2 kg
Key Features
- Supports 4K2K resolution for high-definition video transmission
- Includes 2 HDMI inputs and 1 VGA input for versatile connectivity
- Utilizes HDBaseT technology for long-distance transmission over a single cable
- Ideal for extending video signals in professional AV installations
Professional Installation Requirements
- Installation by a qualified AV technician or electrician is recommended to ensure proper setup and compliance with safety standards.
Applications
- Corporate: Conference rooms and meeting spaces
- Education: Lecture halls and classrooms
- Entertainment: Home theatre and media rooms
- Commercial: Digital signage and display systems
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Reduces the need for multiple cables by consolidating video transmission over a single cable
- Supports energy-efficient video transmission technology
Warranty Information
1 year warranty covering manufacturing defects and hardware failures.
Available Now
The Serveredge 4K2K HDMI x 2, VGA x 1 HDBaseT Extender Over is available now for immediate purchase. Ideal for professional AV installations requiring high-definition video extension over long distances.
