4P AC Contactor 32A | 24V Coil | Screw Terminal by Clipsal
4P AC contactor with 32A current and 24V AC coil—ideal for motor control and automation systems. Built for industrial and commercial use, with screw terminal connections for easy installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: TeSys D, Contactor, TeSys Deca, 4P(4 NO), AC-1, <= 440V, 32A, 24V AC 50/60Hz coil, screw terminal
Brand: Clipsal
SKU: LC1DT32B7
Alternatively Known As: TeSys Deca Contactor, 4P Contactor, AC Contactor
Technical Specifications
- Rated operational voltage: <= 690V AC, 25...400Hz
- Electrical durability: 1 million cycles at 32A AC-1
- Insulation resistance: > 10 MOhm for signalling circuit
- IP degree of protection: IP20
- Rated breaking capacity: 300A at 440V for power circuit
- Control circuit type: AC at 50/60Hz
- Dimensions (H x L x W): 91mm x 99mm x 45mm
- Weight: 0.425 kg
Key Features
- 4 poles with 4 normally open contacts.
- Rated operational current of 32A at <= 440V AC.
- Coil voltage of 24V AC at 50/60Hz.
- Mechanical durability of 15 million cycles.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Motor control, automation systems
- Commercial: HVAC systems, lighting control
Standards & Compliance
- Complies with IEC 60947-4-1 and IEC 60947-5-1 standards.
Environmental Benefits
- Meets environmental regulations and standards.
Warranty Information
18 months warranty against manufacturing defects.
Available Now
The Clipsal TeSys D Contactor is available now for immediate purchase. Ideal for industrial and commercial applications requiring reliable motor control.
