4P Contactor 20A AC1 24VDC | Compact Design | Long Electrical Life | by Clipsal
The 4P Contactor 20A AC1 24VDC is designed for versatile switching applications, featuring a compact design for easy panel integration and a long electrical life of up to 1,000,000 operations. Ideal for lighting control, motor circuits, and HVAC systems, this reliable contactor ensures efficient energy management in commercial and industrial settings.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 4P Contactor 20A AC1 24VDC | Compact Design | Long Electrical Life | by Clipsal
Brand: Clipsal
SKU: SCHLP1K12004BD
Alternatively Known As: 4 Pole Contactor, 20A Contactor, 24VDC Coil Contactor, Clipsal Contactor, SCHLP1K12004BD
Technical Specifications
- Number of Poles: 4
- Rated Operational Current (AC1): 20A
- Coil Voltage: 24V DC
- Utilization Category: AC1
- Conforms to IEC 60947-4-1
- Electrical Life: 1,000,000 operations
- Mechanical Life: 10,000,000 operations
- Mounting: DIN rail
- Ambient Temperature: -5°C to +60°C
- Dimensions (H x L x W): 80mm x 85mm x 45mm
- Weight: 0.3 kg
Key Features
- 4 pole contactor for versatile switching applications
- 20A AC1 rated current for reliable performance
- 24V DC coil for low voltage control
- Compact design for easy panel integration
- Long electrical and mechanical life
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local electrical regulations.
Applications
- Lighting control in commercial and industrial buildings
- Motor control circuits
- HVAC systems
- Switching of resistive and inductive loads
- Automation panels
Standards & Compliance
- Complies with AS/NZS 60947 for low-voltage switchgear and controlgear
Environmental Benefits
- Enables efficient energy management in automation systems
- Supports reduced power consumption through reliable switching
- Long operational life reduces replacement frequency and waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
Available for immediate purchase. Ideal for commercial and industrial automation, lighting, and motor control applications.
