4P Contactor 25A AC1 | 2NO + 2NC Contacts | DIN Rail Mountable | by Clipsal
The 4P Contactor 25A AC1 is designed for efficient control of lighting circuits and HVAC systems, featuring 2 normally open and 2 normally closed contacts. With a rated operational current of 25A and a coil voltage of 48V AC, this compact DIN rail mountable contactor is perfect for commercial and industrial applications, ensuring reliable performance and compliance with AS/NZS standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 4P Contactor 25A AC1 | 2NO + 2NC Contacts | DIN Rail Mountable | by Clipsal
Brand: Clipsal
SKU: SCHLC1D128E7
Alternatively Known As: TeSys D 4 Pole Contactor, 25A Contactor, 2NO 2NC Contactor, Clipsal SCHLC1D128E7, Schneider LC1D128E7
Technical Specifications
- Number of Poles: 4 (2 NO + 2 NC)
- Rated Operational Current: 25A (AC-1)
- Rated Operational Voltage: up to 440V AC
- Coil Voltage: 48V AC
- Utilization Category: AC-1
- Mounting: DIN rail
- Mechanical Durability: 10 million operations
- Electrical Durability: 1 million operations (AC-1)
- Standards: IEC 60947-4-1
- Dimensions (H x L x W): 85mm x 95mm x 45mm
- Weight: 0.35 kg
Key Features
- 4-pole contactor with 2 normally open (NO) and 2 normally closed (NC) contacts
- Rated operational current: 25A (AC-1 duty)
- Suitable for up to 440V AC applications
- 48V AC coil voltage
- TeSys D series for reliable performance
- Compact DIN rail mountable design
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 wiring rules and local regulations.
Applications
- Control of lighting circuits
- HVAC systems
- Motor control in commercial and industrial installations
- Switching of resistive loads in building automation
Standards & Compliance
- Complies with AS/NZS 60947 for low-voltage switchgear and controlgear
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Enables efficient energy management by automating load switching
- Reduces unnecessary power consumption in building automation systems
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal 4P Contactor 25A AC1 (2NO + 2NC) SCHLC1D128E7 is available for immediate purchase. Ideal for commercial and industrial electrical control applications.
