4P Contactor 40A AC-1 | 2NO 2NC Configuration | Compact Design | by Clipsal
The 4P Contactor 40A AC-1 is designed for reliable industrial motor control, featuring a 2NO + 2NC contact configuration. With a rated operational current of 40A and a compact design, it's perfect for control panels, lighting circuits, and HVAC systems. Built for durability with a mechanical life of 10,000,000 operations, this contactor ensures efficient energy management in commercial installations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 4P Contactor 40A AC-1 | 2NO 2NC Configuration | Compact Design | by Clipsal
Brand: Clipsal
SKU: SCHLC1D258SD
Alternatively Known As: 4 pole contactor, 40A contactor, Clipsal contactor, SCHLC1D258SD, 2NO 2NC contactor, industrial contactor
Technical Specifications
- Number of Poles: 4
- Contact Configuration: 2NO + 2NC
- Rated Operational Current (AC-1): 40A
- Rated Operational Voltage: 690V AC
- Control Voltage: 220-240V AC (coil)
- Frequency: 50/60Hz
- Electrical Life: 1,000,000 operations
- Mechanical Life: 10,000,000 operations
- Mounting: DIN rail or panel
- Standards: IEC 60947-4-1
- Dimensions (H x L x W): 85mm x 95mm x 54mm
- Weight: 0.45 kg
Key Features
- 4 pole contactor with 2 normally open (NO) and 2 normally closed (NC) contacts
- Rated operational current: 40A (AC-1)
- Compact design for easy installation in control panels
- Reliable electromagnetic operation
- Suitable for switching resistive and slightly inductive loads
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local wiring rules and standards.
Applications
- Industrial motor control
- Lighting circuits
- HVAC systems
- Switchboards
- Automation panels
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enables efficient energy management in industrial and commercial installations
- Supports automation for reduced manual intervention and energy waste
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal 4P Contactor 40A AC-1 (2NO 2NC) SCHLC1D258SD is available for immediate purchase. Ideal for industrial and commercial control panel applications.
