500AMP 415V AC Type J Fuse | 80 kAIC Interrupting Capacity | Bolt-on Design | by Eaton
The 500AMP 415V AC Type J Fuse is designed for high current protection in industrial electrical systems. With a robust 80 kAIC interrupting capacity and a secure bolt-on design, it ensures reliable performance in low voltage power distribution panels. CE marked and RoHS compliant, this fuse is perfect for both commercial and residential installations requiring 500A protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 500AMP 415V AC Type J Fuse | 80 kAIC Interrupting Capacity | Bolt-on Design | by Eaton
Brand: Eaton
SKU: 500RJ31-7
Alternatively Known As: 500A Type J Fuse, 500RJ31-7 Fuse, Eaton 500A Low Voltage Fuse, British Standard Fuse 500A
Technical Specifications
- Current Rating: 500A
- Voltage Rating: 415V AC
- Interrupting Capacity: 80 kAIC
- Fuse Type: Type J
- Mounting: Bolt-on
- Standards: BS IEC 60269
- Certifications: CE Marked, RoHS Compliant, EAC
- Dimensions (H x L x W): 50mm x 128mm x 50mm
- Weight: 0.44 kg
Key Features
- Bolt-on design for secure and easy installation
- Rated for 500A current and 415V AC voltage
- High interrupting capacity of 80 kAIC
- Complies with British Standard fuse requirements
- CE Marked and RoHS Compliant
Professional Installation Requirements
- Installation must be performed by a qualified electrician to ensure compliance with safety standards and proper fuse operation.
Applications
- Industrial electrical systems requiring high current protection
- Low voltage power distribution panels
- Commercial and residential electrical installations needing 500A fuse protection
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- RoHS compliant ensuring reduced hazardous substances
- Durable design reduces waste through long service life
Warranty Information
Standard Eaton warranty applies, covering manufacturing defects and performance under normal operating conditions.
Available Now
The Eaton Bussmann series 500A 415V AC Type J fuse is available for immediate purchase, ideal for industrial and commercial electrical protection applications.
