52 Inch 3 Blade 40W DC Ceiling Fan | Energy Efficient | Remote Control | Black | by atom
The 52 Inch 3 Blade 40W DC Ceiling Fan is designed for optimal indoor cooling, featuring an energy-efficient DC motor and 8 speed settings controlled via remote. Ideal for both residential and commercial spaces, this fan combines sleek black aesthetics with powerful airflow, ensuring comfort in living rooms, offices, and patios.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: 52 inch DC ceiling fan, 3 blade ceiling fan, energy efficient ceiling fan, remote control ceiling fan, black ceiling fan
Technical Specifications
- Motor Wattage: 40 W
- Motor Type: DC
- Number of Speeds: 8
- RPM Range: 85 to 205
- Airflow Range: 4000 to 12000 m³/hr
- Blade Material: ABS
- Blade Pitch: 13°
- Ceiling Rake: 15°
- Ceiling Drop: 325 mm
- Input Voltage: 230Vac (216-253Vac range)
- Input Frequency: 50 Hz
- IP Rating: IP20
- Working Temperature Range: -10 to 40 °C
- Lamp Power: 19 W
- Colour Temperature Options: 3000K, 4000K, 5000K
- Lumens Output: 1240 lm to 1385 lm
- Dimensions (H x L x W): 325mm x 1320mm x 1320mm
- Weight: 6 kg
Key Features
- 40W DC motor for energy-efficient operation
- 8 speed settings controlled via remote control
- 3 ABS blades with 13° pitch for optimal airflow
- Ceiling rake angle of 15° and ceiling drop of 325mm
- IP20 rated for indoor use
- Tri-CCT lamp configuration with warm white, cool white, and daylight options
Professional Installation Requirements
- Professional installation by a licensed electrician is recommended to ensure compliance with electrical safety standards and optimal fan performance.
Applications
- Residential: Living rooms, bedrooms, patios
- Commercial: Offices, cafes, retail spaces
- General: Indoor cooling and air circulation
Standards & Compliance
- AS/NZS 60335.1
- AS/NZS 60335.2.80
- AS/NZS 60598.1
- AS/NZS 60598.2.2
- AS CISPR 15
- AS/NZS 4268
- AS/NZS CISPR 14
Environmental Benefits
- Energy-efficient DC motor reduces electricity consumption
- Multiple speed settings optimize power use
- Long-lasting ABS blades reduce material waste
Warranty Information
6 years total warranty: 4 years onsite and 2 years return to base for domestic use.
Available Now
The Atom 52 inch 3 Blade 40W DC Ceiling Fan in black is available for immediate purchase, ideal for residential and commercial indoor cooling applications.
