52 Inch 4 Blade 75W AC Ceiling Fan | Matt Black Finish | Wall Control | by atom
The 52 inch 4 Blade 75W AC Ceiling Fan in sleek matt black is designed for optimal air circulation in both residential and commercial spaces. With a powerful 75W AC motor and three speed settings, it ensures efficient airflow and comfort. Ideal for living rooms, bedrooms, and offices, this fan features a durable ABS blade construction and is IP20 rated for indoor use.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: 52 inch ceiling fan, 4 blade ceiling fan, 75W AC ceiling fan, black ceiling fan, Atom ceiling fan
Technical Specifications
- Motor Wattage: 75 W
- Motor Type: AC
- Number of Speeds: 3
- RPM: 220, 133, 93
- Airflow: 16300, 9654, 6185 m³/hr
- Input Voltage: 230Vac (-6%/+10%)
- Input Frequency: 50Hz
- Operating Temperature Range: -10 to 40 °C
- Blade Material: ABS
- Blade Pitch: 13°
- Ceiling Rake: 15°
- Ceiling Drop: 300 mm
- IP Rating: IP20
- Control Type: Wall control
- Dimensions (H x L x W): 350mm x 1320mm x 1320mm
- Weight: 7 kg
Key Features
- 4 blade design with 52 inch (1320mm) span
- 75W AC motor with 3 speed settings
- Wall control for easy operation
- Blade pitch of 13° for efficient airflow
- Ceiling rake of 15° and ceiling drop of 300mm
- ABS blade material with matt black finish
- Operating temperature range from -10 to 40 °C
- IP20 rated for indoor use
Professional Installation Requirements
- Professional installation by a licensed electrician is recommended to ensure compliance with electrical safety standards and optimal fan performance.
Applications
- Residential: Living rooms, bedrooms, patios
- Commercial: Offices, retail spaces, hospitality venues
- General: Indoor cooling and air circulation
Standards & Compliance
- AS/NZS 60335.1
- AS/NZS 60335.2.80
- AS/NZS 60598.1
- AS/NZS 60598.2.2
- AS/NZS CISPR 14
Environmental Benefits
- Energy-efficient AC motor reduces power consumption.
- Durable ABS blades extend product lifespan, reducing waste.
Warranty Information
6 years total warranty: 4 years onsite and 2 years return to base for domestic use.
Available Now
The Atom 52 inch 4 Blade 75W AC Ceiling Fan in black is available for immediate purchase, ideal for enhancing air circulation in residential and commercial indoor environments.
