52 Inch 4 Blade IP66 40W DC Ceiling Fan | Remote Control | ABS Blades | Black | by atom
The 52 inch 4 Blade IP66 40W DC Ceiling Fan is designed for both indoor and outdoor covered areas, providing efficient air circulation with its powerful 40W DC motor and 8 speed settings. With a sleek black finish and durable ABS blades, this fan is perfect for residential, commercial, and industrial applications, ensuring reliable performance even in harsh environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: 52 inch outdoor ceiling fan, IP66 rated ceiling fan, 4 blade DC ceiling fan, remote control ceiling fan
Technical Specifications
- IP Rating: IP66
- Motor Wattage: 40 W
- Motor Type: DC
- Number of Speeds: 8
- Control Type: Remote control
- Blade Material: ABS
- Blade Pitch: 12°
- Ceiling Rake: 15°
- Ceiling Drop: 310 mm
- Fan Size: 1320 mm (52 inch)
- Input Voltage: 230Vac (216Vac - 253Vac range)
- Input Frequency: 50 Hz
- Working Temperature Range: -10 to 40 °C
- Fan Speeds and Airflow:
- Speed 1: 3 W, 75 rpm, 4800 m³/h
- Speed 2: 6 W, 115 rpm, 6700 m³/h
- Speed 3: 15 W, 165 rpm, 8200 m³/h
- Speed 4: 20 W, 190 rpm, 9200 m³/h
- Speed 5: 25 W, 205 rpm, 9400 m³/h
- Speed 6: 30 W, 220 rpm, 10000 m³/h
- Speed 7: 35 W, 230 rpm, 11400 m³/h
- Speed 8: 40 W, 240 rpm, 12600 m³/h
- Dimensions (H x L x W): 310mm x 1320mm x 1320mm
- Weight: 7 kg
Key Features
- IP66 rated for protection against dust and powerful water jets
- 40W DC motor with 8 speed settings controlled via remote
- ABS blade material with 12° blade pitch for efficient air movement
- Ceiling rake angle of 15° and ceiling drop of 310mm
- Suitable for working temperature range from -10 to 40 °C
Professional Installation Requirements
- Professional installation by a licensed electrician is recommended to ensure compliance with electrical safety standards and optimal fan performance.
Applications
- Residential: Indoor and outdoor covered areas
- Commercial: Restaurants, cafes, patios, verandas
- Industrial: Warehouses, workshops with dust and moisture exposure
Standards & Compliance
- Complies with AS/NZS 60335.1
- Complies with AS/NZS 60335.2.80
- Complies with AS/NZS CISPR 14
- Complies with AS/NZS 4268
Environmental Benefits
- Energy-efficient DC motor reduces power consumption
- Durable ABS materials extend product lifespan, reducing waste
- IP66 rating ensures long-term performance in harsh environments
Warranty Information
6 years total warranty: 4 years onsite and 2 years return to base for domestic use.
Available Now
The Atom 52 inch 4 Blade IP66 40W DC Ceiling Fan in black is available for immediate purchase. Ideal for residential, commercial, and industrial applications requiring durable and efficient air circulation.
