54 Inch 3 Blade 32W DC Ceiling Fan | Remote Control | IP20 Rated | Matt Black | by atom
The 54 inch 3 Blade 32W DC Ceiling Fan is designed for efficient air movement with its powerful DC motor and 8 speed settings. Ideal for both residential and commercial spaces, this fan features a sleek matt black finish and remote control operation for convenience. With a blade pitch of 10° and an IP20 rating, it ensures optimal airflow and durability in indoor environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: 54 inch DC ceiling fan, 3 blade ceiling fan, 32W ceiling fan, black ceiling fan, Atom ceiling fan
Technical Specifications
- Motor Wattage: 32 W
- Motor Type: DC
- Number of Speeds: 8
- Fan Size: 1370 mm (54 inch)
- Blade Material: ABS
- Blade Pitch: 10°
- Ceiling Rake: 15°
- Ceiling Drop: 347 mm
- Input Voltage: 230Vac (216Vac - 253Vac range)
- Input Frequency: 50 Hz
- Working Temperature Range: -10 to 40 °C
- Air Movement at Speed 8: 12500 m³/h at 220 rpm
- Control: Remote control
- IP Rating: IP20
- Colour Rendering Index (CRI): >80
- CCT Configuration: TRI-CCT
- Beam Angle: 120°
- Dimensions (H x L x W): 347mm x 1370mm x 1370mm
- Weight: 7 kg
Key Features
- 32W DC motor with 8 speed settings for efficient air movement
- Remote control for convenient operation
- Blade pitch of 10° for optimal airflow
- Ceiling rake of 15° and ceiling drop of 347 mm
- ABS blade material and body for durability
- IP20 rated for indoor use
- Tri-CCT lighting configuration with CRI >80 and 120° beam angle
Professional Installation Requirements
- Professional installation by a licensed electrician is recommended to ensure compliance with electrical safety standards and optimal fan performance.
Applications
- Residential: Living rooms, bedrooms, patios
- Commercial: Offices, cafes, retail spaces
- General: Indoor cooling and air circulation
Standards & Compliance
- Complies with AS/NZS 60335.1
- Complies with AS/NZS 60335.2.80
- Complies with AS/NZS CISPR 14
- Complies with AS/NZS 4268
Environmental Benefits
- Energy-efficient DC motor reduces power consumption compared to traditional AC fans
- Multiple speed settings allow for optimized energy use
- Long-lasting ABS materials reduce waste and replacement frequency
Warranty Information
6 years total warranty: 4 years onsite and 2 years return to base for domestic use.
Available Now
The Atom 54 inch 3 Blade 32W DC Ceiling Fan in black is available for immediate purchase, ideal for residential and commercial indoor cooling applications.
