54 Inch 3 Blade 40W DC Ceiling Fan | Remote Control | IP20 Rated | Matt Black | by atom
The 54 inch 3 Blade 40W DC Ceiling Fan is designed for efficient air circulation in both residential and commercial spaces. With a powerful DC motor offering 8 speed settings and a sleek matt black finish, this fan ensures optimal airflow while being energy-efficient. Ideal for living rooms, offices, and cafes, it features a remote control for convenient operation and operates quietly within a temperature range of -10 to 40 °C.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: 54 inch DC ceiling fan, 3 blade ceiling fan, 40W ceiling fan, Atom black ceiling fan
Technical Specifications
- Motor Wattage: 40 W
- Motor Type: DC
- Number of Speeds: 8
- Fan Size: 1370 mm (54 inch)
- Blade Material: ABS
- Blade Pitch: 15°
- Ceiling Rake: 15°
- Ceiling Drop: 300 mm
- Input Voltage: 230 Vac (216-253 Vac range)
- Input Frequency: 50 Hz
- Operating Temperature Range: -10 to 40 °C
- Air Movement at Speed 8: 16200 m³/h at 210 rpm
- Control: Remote control
- IP Rating: IP20
- Colour Rendering Index (CRI): >80
- CCT Configuration: TRI-CCT
- Dimensions (H x L x W): 400mm x 1370mm x 1370mm
- Weight: 6 kg
Key Features
- 40W DC motor with 8 speed settings for efficient air movement
- Remote control for convenient operation
- ABS blade material with 15° blade pitch for optimal airflow
- Ceiling rake of 15° and ceiling drop of 300 mm
- Tri-CCT lamp configuration with CRI >80
- IP20 rated for indoor use
- Operating temperature range from -10 to 40 °C
Professional Installation Requirements
- Professional installation by a licensed electrician is recommended to ensure compliance with electrical safety standards and optimal fan performance.
Applications
- Residential: Living rooms, bedrooms, kitchens
- Commercial: Offices, cafes, retail spaces
- General: Indoor cooling and air circulation
Standards & Compliance
- AS/NZS 60335.1
- AS/NZS 60335.2.80
- AS CISPR 14
- AS/NZS 4268
- AS/NZS 60598.1
- AS/NZS 60598.2.2
- AS CISPR 15
Environmental Benefits
- Energy-efficient DC motor reduces power consumption compared to traditional AC fans
- Multiple speed settings allow for optimized energy use
- Long-lasting motor and durable ABS blades reduce waste and replacement frequency
Warranty Information
6 years total warranty: 4 years onsite and 2 years return to base (RTB) for domestic use.
Available Now
The Atom 54 inch 3 Blade 40W DC Ceiling Fan in black is available for immediate purchase, ideal for residential and commercial indoor cooling applications.
