PL 3300V 300A 6 Pin Receptacle (270) 50-C

6 Pin Receptacle 300A | 660V to 3300V | IP55 Rated | Quick Release by Ausproof

BRAND: Ausproof

SKU: RS1550

$1,868.60 List price: $2,320.80

+ −

30 Days Return Delivery Options

The 6 pin receptacle with a 300A current rating and voltage range of 660V to 3300V is ideal for mining and hazardous environments. Built for safety and compliance, it features quick release and stainless steel construction for durability.

Description

Product Name/Title: PL 3300V 300A 6 Pin Receptacle (270) 50-C

Brand: Ausproof

SKU: RS1550

Alternatively Known As: PL Range 6 Pin Receptacle, Ex-certified 300A Receptacle, Mining Grade Electrical Receptacle

Technical Specifications

Voltage Range: 660V to 3300V
Current Rating: 300A to 425A
Material: Stainless Steel
Ingress Protection: IP55
Through Fault Current (Phase): 2 tests of 25.0kA for 0.2 seconds
Through Fault Current (Earth): 2 tests of 8.0kA for 0.2 seconds
AC HV Withstand (Phase): 8.6kV for one minute
AC HV Withstand (Pilot): 1.0kV for one minute
Temperature Rise: Rated for 300A and 425A
Plug Weight: 9.0 kg
Receptacle Weight: 10.7 kg
Compliant to: AS/NZS 1299, IEC 60079-0, IEC 60079-1
Dimensions (H x L x W): 300mm x 150mm x 200mm
Weight: 10.7 kg

Key Features

Quick Release
Single piece contacts to prevent hot joints
Easy termination
Easy flameproof repair
Full solid earth connectivity throughout product
Full phase to phase segregation with earth
Lightest Ex product on the market
Silicone Protection Cover
Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles

Professional Installation Requirements

Professional installation by qualified electricians trained in hazardous area electrical equipment is required to ensure safety and compliance.

Applications

Mining
Tunnelling
Commercial applications
Group 1 hazardous environments

Standards & Compliance

Complies with AS/NZS 1299 – Electrical Equipment for Explosive Atmospheres

Environmental Benefits

Durable stainless steel construction reduces need for frequent replacements, minimizing waste.
Flameproof repairable design reduces environmental impact by allowing on-site repairs.

Warranty Information

Standard manufacturer warranty applies. Please contact Ausproof for detailed warranty terms.

Available Now

The Ausproof PL 3300V 300A 6 Pin Receptacle is available now for immediate purchase. Ideal for mining, tunnelling, and hazardous commercial applications.
