6 Pin Receptacle 300A | IP55 Rated | Quick Release & Flameproof Design | Ausproof
The 6 pin receptacle with a 300A current rating and IP55 ingress protection is ideal for mining and tunnelling applications. Built for hazardous environments, it features quick release functionality and a durable stainless steel construction for enhanced safety.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: PL 1100V 300A 6 Pin Receptacle (90) 70-C
Brand: Ausproof
SKU: RS1479
Alternatively Known As: PL Range 6 Pin Receptacle, Ex-certified 300A Receptacle, Flameproof Electrical Connector
Technical Specifications
- Operating Voltage: 660V to 3300V
- Current Rating: 300A to 425A
- Material: Stainless Steel
- Ingress Protection: IP55
- Through Fault Current (Phase): 2 Tests of 25.0kA for 0.2 seconds
- Through Fault Current (Earth): 2 Tests of 8.0kA for 0.2 seconds
- AC HV Withstand (Phase): 8.6kV for one minute
- AC HV Withstand (Pilot): 1.0kV for one minute
- Temperature Rise: Suitable for 300A and 425A ratings
- Dimensions (H x L x W): 200mm x 150mm x 150mm
- Weight: 10.7 kg
Key Features
- Quick Release
- Single piece contacts to prevent hot joints
- Easy termination
- Easy flameproof repair
- Full solid earth connectivity throughout product
- Full phase to phase segregation with earth
- Lightest Ex product on the market
- Silicone Protection Cover
- Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles
Professional Installation Requirements
- Installation must be performed by a qualified electrician experienced with Ex-certified equipment and hazardous area installations.
Applications
- Mining
- Tunnelling
- Commercial applications
- Group 1 hazardous environments
Standards & Compliance
- Complies with AS/NZS 1299 – Electrical Equipment for Explosive Atmospheres
Environmental Benefits
- Durable stainless steel construction reduces need for frequent replacements.
- Flameproof design enhances safety, reducing risk of environmental hazards.
Warranty Information
Warranty details available upon request; typically includes coverage against manufacturing defects.
Available Now
The Ausproof PL 1100V 300A 6 Pin Receptacle is available now for immediate purchase. Ideal for mining, tunnelling, and hazardous commercial applications.
