6 Pin Receptacle 300A | IP55 Rated | Quick Release & Stainless Steel | Ausproof
The 6 pin receptacle with a 300A current rating and IP55 ingress protection is ideal for mining and tunnelling applications. Built for hazardous environments, it features quick release functionality and durable stainless steel construction for enhanced safety and longevity.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: PL 1100V 300A 6 Pin Receptacle (90) 25-C
Brand: Ausproof
SKU: RS1476
Alternatively Known As: PL Range 6 Pin Receptacle, Ex-certified 300A Receptacle, Flameproof Electrical Connector
Technical Specifications
- Voltage Range: 660V to 3300V
- Current Rating: 300A to 425A
- Material: Stainless Steel
- Ingress Protection: IP55
- Through Fault Current (Phase): 2 tests of 25.0kA for 0.2 seconds
- Through Fault Current (Earth): 2 tests of 8.0kA for 0.2 seconds
- AC HV Withstand (Phase): 8.6kV for one minute
- AC HV Withstand (Pilot): 1.0kV for one minute
- Temperature Rise: Rated for 300A and 425A
- Compliance: AS/NZS 1299, IEC 60079-0, IEC 60079-1
- Dimensions (H x L x W): 250mm x 150mm x 200mm
- Weight: 10.7 kg
Key Features
- Quick Release
- Single piece contacts to prevent hot joints
- Easy termination
- Easy flameproof repair
- Full solid earth connectivity throughout product
- Full phase to phase segregation with earth
- Lightest Ex product on the market
- Silicone Protection Cover
- Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles
Professional Installation Requirements
- Professional installation by qualified personnel trained in hazardous area electrical equipment is required to ensure safety and compliance.
Applications
- Mining
- Tunnelling
- Commercial applications
- Group 1 hazardous environments
Standards & Compliance
- Complies with AS/NZS 1299 for electrical equipment in hazardous areas.
Environmental Benefits
- Durable stainless steel construction reduces waste and extends product life.
- Easy flameproof repair reduces need for full replacements, minimizing material waste.
Warranty Information
Standard manufacturer warranty applies. Please contact Ausproof for detailed warranty terms.
Available Now
The Ausproof PL 1100V 300A 6 Pin Receptacle is available now for immediate purchase. Ideal for mining, tunnelling, and commercial hazardous environment applications.
