600VA Line-Interactive UPS ECO

BRAND: CABAC
SKU: ECO600
$98.70 List price: $131.60
+ −
30 Days Return Electricians Unlock Trade Access
ECO 600VA line-interactive UPS features LED display, surge protection and auto-restart. Ideal for CCTV, computers, point of sale, modems and NBN.

Alternatively Known As: ECO 600VA UPS, ECO600 Battery Backup UPS, ECO Series UPS

Technical Specifications
  • Capacity: 600VA / 360W
  • Input Voltage: 230Vac
  • AVR Voltage Range: 162-290Vac
  • Frequency Range: 50Hz ±10%
  • Output Voltage Regulation: 230Vac ±10%
  • Output Waveform: Modified/simulated sine wave
  • Transfer Time: Typically 2-6ms
  • Output Sockets: 2 x Australian Type I 10A UPS outlets
  • Battery Type: Sealed lead-acid, maintenance-free
  • Battery Configuration: 1 x 12V 7Ah
  • Recharge Time: 6-8 hours to 90% capacity after complete discharge
  • Surge Protection: 125 joules / 4500A
  • Display: LED status indicators
  • Audible Noise: Less than 30dB
  • Operating Temperature: 0-40°C
  • Operating Humidity: 0-90% RH, non-condensing
  • Auto Restart: Yes
  • Automatic Voltage Regulation: Yes
  • Cold Start: Yes
  • Dimensions (H x L x W): 140mm x 300mm x 95mm
  • Weight: 4 kg
Key Features
  • Line-interactive UPS topology with automatic voltage regulation
  • 600VA / 360W capacity for compatible electronic equipment
  • LED indicators for mains presence, battery charge, mains failure and fault status
  • Provides battery backup during mains power failure
  • Surge protection and short-circuit protection
  • Automatic restart when mains power returns
  • Two Australian Type I 10A UPS output sockets
  • Suitable for CCTV, computers, point-of-sale equipment, modems and NBN devices
Professional Installation Requirements
  • No professional installation is normally required for this plug-in UPS. Connect to a suitable earthed Australian mains outlet and observe the manufacturer's load and ventilation requirements. Battery servicing or replacement should be performed by suitably qualified personnel.
Applications
  • CCTV and security surveillance systems
  • Desktop computers and peripheral equipment
  • Point-of-sale systems
  • Modems, routers and NBN equipment
  • Telecommunications equipment
  • Home and office workstations
Standards & Compliance
  • AS 62040.1: Applicable Australian safety standard for portable uninterruptible power supplies
  • AS/NZS 3112: Australian Type I 10A socket format
Environmental Benefits
  • Sealed lead-acid battery technology is recyclable through appropriate battery-recycling channels
  • Automatic voltage regulation can reduce equipment stress and avoidable energy losses caused by voltage fluctuations
  • Replaceable battery design can extend the usable life of the UPS and reduce electronic waste
  • The enclosure and electronic components should be disposed of through approved electrical and battery-recycling services
Warranty Information

Specific ECO600 warranty duration was not published in the available manufacturer and distributor documentation. Australian Consumer Law consumer guarantees apply; confirm any additional supplier warranty at purchase.

Available Now

Available through ECO-branded suppliers and authorised Australian electrical, security and technology distributors.

UPS Sizing Calculator




This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
