63A MID Energy Meter RS-485 | Class 1 Accuracy | Multi-Tariff Support | Compact DIN Rail Mounting | @Pack of 1 | by Clipsal
The 63A MID Energy Meter RS-485 is designed for precise energy monitoring in commercial and industrial applications. With Class 1 accuracy and multi-tariff capability, it’s perfect for billing and energy management systems. Featuring RS-485 Modbus communication, this compact meter integrates seamlessly with BMS and SCADA systems, ensuring efficient load profiling and cost allocation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 63A MID Energy Meter RS-485 | Class 1 Accuracy | Multi-Tariff Support | Compact DIN Rail Mounting | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHA9MEM3155-NMI
Alternatively Known As: iEM3155 Energy Meter, Schneider iEM3155, MID Certified Energy Meter, RS-485 Modbus Energy Meter, SCHA9MEM3155-NMI
Technical Specifications
- Rated current: 63A direct connection
- Accuracy class: Class 1 (IEC 62053-21)
- MID certified (EN 50470-1/3)
- Voltage: 230/400V AC (50/60Hz)
- Communication: RS-485 Modbus RTU
- Inputs/Outputs: 1 digital input, 1 digital output
- Multi-tariff capability
- Display: LCD with backlight
- Mounting: DIN rail
- Operating temperature: -25°C to +55°C
- Dimensions (H x L x W): 90mm x 65mm x 72mm
- Weight: 0.3 kg
Key Features
- 63A direct connection for three-phase or single-phase systems
- MID certified for billing applications
- Class 1 accuracy for precise energy measurement
- RS-485 Modbus communication for integration with BMS and SCADA
- Multi-tariff support for advanced billing
- 1 digital input and 1 digital output for flexible control
- Compact DIN rail mounting
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local electrical regulations and standards.
Applications
- Commercial and industrial energy monitoring
- Sub-metering in multi-tenant buildings
- Energy management systems
- Load profiling and cost allocation
Standards & Compliance
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enables precise energy monitoring to support energy efficiency initiatives
- Facilitates load management and reduction of unnecessary energy consumption
- Supports compliance with energy management standards
Warranty Information
2 years manufacturer's warranty.
Available Now
The Clipsal iEM3155 63A Class 1 MID Energy Meter RS-485 is available for immediate purchase. Ideal for commercial and industrial energy monitoring and billing applications.
