65mm BSP Threaded Storz x 80mm Roll Groove Inlet | Brass Construction | UV Plastic Cap | 1,400 kPa Working Pressure by Firebox
This 65mm BSP threaded Storz x 80mm roll groove inlet is designed for fire hydrant systems in NSW, SA, ACT, and TAS. Constructed from durable brass with a painted red finish, it features a UV plastic cap and a working pressure of 1,400 kPa, making it ideal for reliable fire protection infrastructure.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 65mm BSP Threaded Storz x 80mm Roll Groove Inlet | Brass Construction | UV Plastic Cap | 1,400 kPa Working Pressure by Firebox
Brand: Firebox
SKU: HVSTZRG-BR
Alternatively Known As: 65mm BSP Storz Fire Hydrant Inlet, 80mm Roll Groove Fire Hydrant Connection, Firebox Storz Inlet
Technical Specifications
- Thread type: 65mm BSP forged Storz adaptor with UV plastic cap
- Inlet type: 80mm roll grooved with 65mm BSP internal thread
- Construction: Brass body with painted red finish
- Hand wheel construction: C steel
- Working pressure: 1,400 kPa
- Test pressure: 3,200 kPa
- Unit weight: 4.5 kg
- Dimensions (H x L x W): 65mm x 150mm x 80mm
- Weight: 4.5 kg
Key Features
- 65mm BSP male inlet with forged Storz adaptor and UV plastic cap
- 80mm roll grooved inlet with 65mm BSP internal thread
- Constructed from durable brass with painted red finish
- Hand wheel made from C steel
- Working pressure of 1,400 kPa and test pressure of 3,200 kPa
- Certified with Global-Mark ID 109076
Professional Installation Requirements
- Installation should be performed by a qualified professional experienced in fire protection systems to ensure compliance with local regulations and standards.
Applications
- Fire hydrant systems in NSW, SA, ACT, VIC, and TAS
- Suitable for fire protection infrastructure requiring 65mm BSP threaded Storz connections
Standards & Compliance
- AS/NZS 2419 – Fire Hydrant Systems
Environmental Benefits
- Durable brass construction reduces need for frequent replacements, minimizing waste
- Painted finish enhances longevity, reducing environmental impact of corrosion
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Firebox 65mm BSP Threaded Storz x 80mm Roll Groove Inlet is available now for immediate purchase. Ideal for fire hydrant system installations in NSW, SA, ACT, VIC, and TAS.
