6kVA 6kW Online UPS 1 Battery Bank Rack Tower Enduro
Enduro 6kVA 6kW online double conversion UPS features 1 battery bank, 10 year design life batteries and rack or tower mounting. Ideal for servers.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: ENDURO EN6000 UPS, PSS Enduro 6000VA UPS, 6kVA Rack/Tower UPS, 6kW Server UPS
Technical Specifications
- Capacity: 6000VA / 6000W
- Topology: Online double conversion
- Input Voltage: 230V AC ±20%
- Input Frequency: 45–65Hz
- Output Voltage Regulation: 230V AC ±2%
- Output Frequency: 50Hz ±0.1Hz
- Output Waveform: Pure sinewave
- Output Power Factor: 1.0
- Input Power Factor: 0.99
- Battery Type: Sealed lead-acid, maintenance-free
- Battery Configuration: 16 x 12V 9Ah batteries
- Battery Design Life: 10 years
- Recharge Time: Approximately 5 hours to 90% after complete discharge
- Communications: USB and RS-232 standard; optional SNMP and relay card
- Protection: Surge, short-circuit, overload, battery and emergency power-off protection
- Noise Level: Less than 50dB at 1m
- Operating Temperature: 0–40°C
- Relative Humidity: 0–95%, non-condensing
- Runtime at Full 6kW Load: Approximately 7 minutes
- Mounting: Rack or tower
- Compliance Marking: RCM/C-Tick; EMC to EN50091-2
- Dimensions (H x L x W): 217mm x 443mm x 580mm
- Weight: 78.3 kg
Key Features
- True online double-conversion technology for continuous power conditioning
- 6kVA and 6kW capacity with unity output power factor
- Pure sinewave output for servers and other sensitive electronic equipment
- Rack or tower installation options
- One integrated battery bank with provision for extended battery modules
- Interactive LCD display for operating and load information
- USB and RS-232 communications interfaces
- Optional SNMP and relay-card monitoring
- Emergency power-off function
- Generator compatible
- Network surge protection
- Smart management and shutdown software support
Professional Installation Requirements
- Installation and commissioning should be performed by a licensed electrician or suitably qualified UPS technician. Hardwired mains and battery connections must comply with AS/NZS 3000 and the manufacturer's installation instructions. Provide appropriate ventilation, clearance, earthing, isolation and battery safety controls.
Applications
- Server rooms and data centres
- Network and telecommunications equipment
- Industrial control systems
- Point-of-sale systems
- Security and camera surveillance systems
- Telephone systems
- Critical office and computer equipment
Standards & Compliance
- AS 62040.1: Applicable UPS safety standard
- AS IEC 62040.3: Applicable UPS performance and testing standard
- AS/NZS 3000:2018: Electrical installation and wiring requirements for permanent installation
- RCM/C-Tick and EN50091-2 EMC compliance are identified in the product documentation
Environmental Benefits
- Unity output power factor and 0.99 input power factor support efficient power utilisation
- Online power conditioning can reduce stress on connected equipment and help extend service life
- 10-year battery design life can reduce replacement frequency and associated battery waste
- Sealed lead-acid batteries should be recycled through an authorised battery-recycling programme at end of life
Warranty Information
PSS Distributors' standard warranty is a 2-year return-to-base warranty from the original purchase date, covering defects in materials and workmanship subject to the published installation, operating and maintenance conditions. Battery warranty terms may differ where separately specified.
Available Now
Available through ENDURO/PSS distributors and authorised Australian resellers; contact the distributor to confirm current stock and configuration.
UPS Sizing Calculator
This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
