6kVA 6kW Online UPS 2 Battery Banks Rack Tower Enduro

BRAND: CABAC
SKU: EN6-2-RT-LL
$7,112.80 List price: $9,483.80
Free pick up (over 25 kg or over 1 meter)
Contact us for delivery cost
30 Days Return Electricians Unlock Trade Access
Enduro 6kVA 6kW online double conversion UPS features 2 battery banks, 10 year design life batteries and rack or tower mounting. Ideal for servers.

Alternatively Known As: ENDURO 6000VA UPS, EN6000 UPS with 2 EBM, rack/tower online UPS

Technical Specifications
  • Model: EN6-2-RT-LL
  • Capacity: 6kVA / 6kW
  • Topology: Online double conversion
  • Phase: Single phase, 1:1
  • Input Voltage: 230V ±20%
  • Input Frequency: 45–65Hz
  • Output Voltage: 230V AC ±2%
  • Output Frequency in Battery Mode: 50Hz ±0.1Hz
  • Output Waveform: Pure sinewave
  • Output Power Factor: 1.0
  • Input Power Factor: ≥0.98
  • Total Harmonic Distortion: ≤3% linear load; ≤5% non-linear load
  • Battery Type: Sealed lead-acid, maintenance-free
  • Battery Configuration: 16 x 12V / 9Ah internal battery arrangement, plus two extended battery modules
  • Battery Design Life: 10 years with long-life battery upgrade
  • Full-Load Runtime with Two EBMs: Approximately 22 minutes at 6kW; manufacturer estimate
  • Recharge Time: Approximately 5 hours to 90%
  • Efficiency: ≥89–92% in normal mode; up to 97% in ECO mode
  • Communications: USB and RS-232; optional SNMP and relay cards
  • Protection: Input surge protection, resettable circuit breaker, audible alarms and EPO
  • Installation Connection: Hardwired input and output
  • UPS Module Dimensions: 443W x 580D x 217H mm; 5RU
  • Battery Module Dimensions: 443W x 580D x 131H mm; 3RU each
  • UPS Module Weight: 78.3kg
  • Battery Module Weight: 63kg each
  • Environmental Operating Range: 0°C to 40°C; 0–95% relative humidity, non-condensing
  • Noise Level: Less than 50dB at 1m
  • EMC and Marking: EN50091-2; C-Tick/RCM listed in product brochure
  • Dimensions (H x L x W): 479mm x 580mm x 443mm
  • Weight: 204.3 kg
Key Features
  • Online double-conversion power protection for servers and other sensitive equipment
  • 6kVA and 6kW unity-power-factor output
  • Supplied with two extended battery banks for increased runtime
  • Rack-mountable or tower-mountable configuration
  • Pure sinewave output with interactive LCD display
  • Generator-compatible design
  • USB and RS-232 communications included
  • Optional SNMP and relay cards for network monitoring and dry-contact integration
  • Emergency power off function
  • 10-year design-life battery option
Professional Installation Requirements
  • Installation and commissioning should be performed by a licensed electrician or suitably qualified UPS technician. The unit has hardwired input and output connections and must be installed, earthed, commissioned and maintained in accordance with the manufacturer’s instructions and applicable Australian electrical requirements, including AS/NZS 3000.
Applications
  • Server rooms and data centres
  • Telecommunications and network infrastructure
  • Industrial control and automation equipment
  • Point-of-sale systems
  • CCTV and security surveillance systems
  • Computer rooms and other sensitive electronic equipment installations
Standards & Compliance
  • AS 62040.1:2019 – applicable Australian UPS safety requirements
  • AS IEC 62040.2:2019 – applicable UPS electromagnetic compatibility requirements
  • AS IEC 62040.3 – UPS performance and test requirements
  • AS/NZS 3000:2018 – electrical installation, isolation, earthing and wiring requirements
Environmental Benefits
  • 10-year design-life batteries can reduce replacement frequency and battery waste compared with shorter-life alternatives
  • ECO mode efficiency of up to 97% can reduce operating energy consumption under suitable load conditions
  • Sealed lead-acid batteries should be recovered and recycled through an approved battery recycling channel at end of life
  • Extended battery runtime can help maintain critical equipment operation without immediate generator intervention
Warranty Information

PSS Distributors’ standard warranty is a 2-year return-to-base warranty from the original purchase date, subject to installation, operating and maintenance conditions. Transportation is generally excluded from the standard warranty. ([pssdistributors.com.au](https://www.pssdistributors.com.au/ups-warranty/?utm_source=openai))

Available Now

Available through ENDURO/PSS channels and authorised Australian distributors; confirm current stock and lead time with the distributor. ([cabac.com.au](https://www.cabac.com.au/p/power-supplies-batteries/uninterruptible-power-supplies/line-interactive-ups/en6-2-rt-ll?utm_source=openai))

UPS Sizing Calculator




This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
