6kVA 6kW Online UPS 3 Battery Banks Rack Tower Enduro

BRAND: CABAC
SKU: EN6-3-RT-LL
$9,229.20 List price: $12,305.60
Free pick up (over 25 kg or over 1 meter)
Contact us for delivery cost
30 Days Return Electricians Unlock Trade Access
Enduro 6kVA 6kW online double conversion UPS features 3 battery banks, 10 year design life batteries and rack or tower mounting. Ideal for servers.

Alternatively Known As: ENDURO EN6-3-RT-LL, EN6000 + 3 EBM, 6kVA Rack/Tower UPS

Technical Specifications
  • Capacity: 6kVA / 6kW
  • Topology: Online double conversion
  • Phase: Single phase, 1:1
  • Input Voltage: 230V ±20%
  • Output Voltage: 230V ±2%
  • Input Power Factor: ≥0.98
  • Output Power Factor: 1.0
  • Output Waveform: Pure sinewave
  • Input and Output Connection: Hardwired L+N+E
  • Battery Type: Sealed lead-acid, maintenance-free
  • Battery Configuration: 16 × 12V 9Ah per UPS module
  • Extended Battery Modules: 3 EBM units included
  • Battery Design Life: 10 years with long-life battery option
  • Full-Load Runtime: Approximately 30 minutes with three EBMs
  • Efficiency: 89–92% normal mode; up to 97% ECO mode
  • Communications: USB and RS-232 standard; optional SNMP and relay cards
  • Protection and Control: EPO, input breaker, overload and short-circuit protection
  • Operating Temperature: 0–40°C
  • Relative Humidity: 0–95% non-condensing
  • Noise Level: Less than 50dB at 1m
  • Rack Height: 5RU UPS module plus three 3RU battery modules
  • Source: ENDURO 6–10kVA manufacturer/distributor brochure and product listing ([d347awuzx0kdse.cloudfront.net](https://d347awuzx0kdse.cloudfront.net/netdigital/product-download/en6000_1.pdf?v=e48805e2c1994332fb6d036d8696e12a26dc9385&utm_source=openai))
  • Dimensions (H x L x W): 610mm x 580mm x 443mm
  • Weight: 267.3 kg
Key Features
  • Online double-conversion technology for continuous power conditioning
  • 6kVA and 6kW unity-power-factor output capacity
  • Pure sinewave output suitable for servers and other sensitive equipment
  • Includes three extended battery modules for increased runtime
  • Approximately 30 minutes runtime at a 6kVA/6kW load with three EBMs
  • Rack-mount or tower-mount installation
  • Interactive LCD status display
  • Emergency power-off function
  • Generator compatible
  • Optional SNMP and voltage-free relay monitoring cards
  • 10-year design-life battery option
  • Smart battery charging and UPS management software
Professional Installation Requirements
  • Installation and commissioning must be performed by a suitably qualified electrical contractor. The unit has hardwired mains input and output connections and should be installed in accordance with AS/NZS 3000, the manufacturer's instructions and applicable UPS safety requirements. PSS warranty terms state that hardwired products must be commissioned by an approved and authorised PSS technician or contractor. ([pssdistributors.com.au](https://www.pssdistributors.com.au/ups-warranty/?utm_source=openai))
Applications
  • Server rooms and data centres
  • Telecommunications and network equipment
  • Industrial control and automation systems
  • Point-of-sale systems
  • CCTV and security infrastructure
  • Computer rooms and other critical electronic loads
Standards & Compliance
  • AS 62040.1: applicable Australian safety standard for uninterruptible power systems; product certification was not independently confirmed from the available sources
  • AS/NZS 3000: applicable to hardwired electrical installation and commissioning
Environmental Benefits
  • High-efficiency ECO mode can reduce operating energy consumption, with efficiency up to 97%
  • Extended battery modules and replaceable sealed lead-acid batteries can extend system service life and reduce replacement waste
  • Lead-acid batteries are recoverable through appropriate battery recycling programs
  • Online power conditioning can help protect connected equipment from voltage disturbances and reduce premature equipment replacement
Warranty Information

PSS Distributors' standard warranty is a 2-year return-to-base warranty from the original purchase date. Transportation is generally excluded, and hardwired products require approved commissioning for warranty validity. ([pssdistributors.com.au](https://www.pssdistributors.com.au/ups-warranty/?utm_source=openai))

Available Now

Available through ENDURO/PSS and authorised Australian electrical and data-comms distributors; contact the distributor to confirm current stock and lead time. ([mssdatasolutions.com.au](https://www.mssdatasolutions.com.au/p/power-supplies-batteries/uninterruptible-power-supplies/line-interactive-ups/en6-3-rt-ll))

UPS Sizing Calculator




This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
