6kVA 6kW Online UPS 4 Battery Banks Rack Tower Enduro

BRAND: CABAC
SKU: EN6-4-RT-LL
$11,345.60 List price: $15,127.50
Free pick up (over 25 kg or over 1 meter)
Contact us for delivery cost
30 Days Return Electricians Unlock Trade Access
Enduro 6kVA 6kW online double conversion UPS features 4 battery banks, 10 year design life batteries and rack or tower mounting. Ideal for servers.

Alternatively Known As: ENDURO 6kVA UPS, EN6-3-RT-LL, EN6000 UPS, Rack/Tower Online UPS, 6kVA Server UPS

Technical Specifications
  • Capacity: 6kVA / 6kW
  • Topology: Online double conversion
  • Input: 230V ±20%, single phase
  • Input frequency range: 45–65Hz
  • Input power factor: ≥0.98
  • Input connection: Hardwired L+N+E, 40A breaker
  • Output voltage: 230V AC ±2%
  • Output power factor: 1.0
  • Output waveform: Pure sinewave
  • Output frequency on battery: 50Hz ±0.1Hz
  • Output connection: Hardwired L+N+E
  • Efficiency: 89–92% in normal mode; up to 97% in ECO mode
  • Overload capacity: 30 seconds at 100–150%; 300ms at ≥150%
  • Battery type: Sealed lead-acid, maintenance-free
  • Battery configuration: 16 × 12V 9Ah internal battery string; supplied with 3 extended battery modules
  • Battery design life: 10 years with long-life battery option
  • Recharge time: Approximately 5 hours to 90%
  • Communications: USB and RS-232 standard; optional SNMP and relay cards
  • Controls: LCD display for load, battery, input, output and operating status
  • Protection: EPO, resettable circuit breaker, surge protection and short-circuit protection
  • Operating temperature: 0–40°C
  • Relative humidity: 0–95%, non-condensing
  • Noise level: <50dB at 1m
  • Manufacturer-stated EMC/compliance marking: EN50091-2 and C-Tick/RCM
  • UPS module dimensions: 443W × 580D × 217H mm; 5RU
  • Each extended battery module: 443W × 580D × 131H mm; 3RU
  • Runtime at full 6kW load: Approximately 6 minutes with the standard internal battery configuration; runtime varies with load and battery condition
  • Dimensions (H x L x W): 610mm x 580mm x 443mm
  • Weight: 267.3 kg
Key Features
  • Online double-conversion protection for servers and other sensitive electronic equipment
  • 6kVA capacity matched to a 6kW unity-power-factor output
  • Includes three extended battery modules, providing four battery cabinets including the UPS module
  • Rack-mountable or tower-configurable installation
  • Pure sinewave output with output voltage regulation to ±2%
  • 10-year design-life battery option
  • ECO mode efficiency of up to 97%
  • Generator-compatible design
  • LCD monitoring with USB and RS-232 communications
  • Optional SNMP network management and relay interface cards
  • Emergency power-off function for controlled shutdown
  • Expandable runtime through additional extended battery modules
Professional Installation Requirements
  • Professional installation and commissioning are required. The UPS has hardwired 40A input and output connections and should be installed by a suitably qualified electrician or authorised UPS technician in accordance with the manufacturer’s instructions, applicable electrical requirements and AS 62040.1. Adequate ventilation, battery isolation, load testing and commissioning should be provided.
Applications
  • Server rooms and data centres
  • Network and telecommunications equipment
  • Security and CCTV systems
  • Point-of-sale systems
  • Industrial control and automation equipment
  • Computer rooms and other critical single-phase loads
Standards & Compliance
  • AS 62040.1 – applicable Australian safety standard for uninterruptible power supplies; specific EN6000 certification was not independently confirmed
  • RCM/C-Tick marking is stated in the product documentation; registration and certification details should be confirmed before installation
Environmental Benefits
  • 10-year design-life battery option can reduce replacement frequency and battery waste compared with shorter-life alternatives
  • ECO operating mode can reduce energy consumption and heat generation when operating conditions allow
  • Sealed lead-acid batteries are recoverable through appropriate battery recycling programs
  • Modular extended battery design allows runtime capacity to be matched to the application rather than replacing the complete UPS system
Warranty Information

Standard PSS Distributors warranty is a 2-year return-to-base warranty covering defects in materials and workmanship, subject to installation, operating-condition and commissioning requirements. Transportation is generally excluded from the standard RTB warranty. ([pssdistributors.com.au](https://www.pssdistributors.com.au/ups-warranty/?utm_source=openai))

Available Now

Available through ENDURO/PSS distribution channels and authorised Australian electrical and technology distributors; live stock and lead times should be confirmed before ordering. ([mssdatasolutions.com.au](https://www.mssdatasolutions.com.au/p/power-supplies-batteries/uninterruptible-power-supplies/line-interactive-ups/en6-3-rt-ll))

UPS Sizing Calculator




This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
