6kVA 6kW Online UPS 5 Battery Banks Rack Tower Enduro
Enduro 6kVA 6kW online double conversion UPS features 5 battery banks, 10 year design life batteries and rack or tower mounting. Ideal for servers.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Enduro EN6000+4EBM UPS, 6kVA Rack/Tower UPS, Online Double-Conversion UPS, Extended Battery Module UPS
Technical Specifications
- Model: EN6000+4EBM
- Capacity: 6kVA / 6kW
- Topology: Online double conversion
- Phase: Single phase input and output
- Input Voltage: 230V ±20%
- Input Frequency: 45–65Hz
- Output Voltage: 230VAC ±2%
- Output Frequency in Battery Mode: 50Hz ±0.1Hz
- Output Power Factor: 1.0
- Waveform: Pure sinewave
- Total Harmonic Distortion: ≤3% linear load; ≤5% non-linear load
- Battery Type: Sealed lead-acid, maintenance-free
- Standard UPS Battery Configuration: 16 × 12V / 9Ah
- Battery Banks: UPS module plus four extended battery modules
- Battery Design Life: 10 years with long-life battery upgrade
- Recharge Time to 90%: 5 hours
- Efficiency: 89–92% normal mode; up to 97% ECO mode
- Communications: USB and RS-232 standard; optional SNMP and relay cards
- Protection: 2,200 joules surge protection; resettable circuit breaker; EPO
- Noise Level: <50dB at 1m
- Full-Load Runtime with Four EBMs: Approximately 38 minutes
- Compliance: EN50091-2; C-Tick/RCM marking
- Dimensions (H x L x W): 800mm x 580mm x 443mm
- Weight: 303 kg
Key Features
- Online double-conversion power protection for continuous conditioned output
- 6kVA / 6kW capacity with unity output power factor
- Five battery banks provide extended runtime for critical loads
- Compatible with 10-year design-life battery configuration
- Rack or tower mounting configuration
- Pure sinewave output suitable for servers and sensitive electronic equipment
- Interactive LCD monitoring and smart management software
- Generator compatible
- Emergency Power Off function
- Optional SNMP and relay communications cards
- Estimated 38-minute runtime at 6kW load with four extended battery modules
Professional Installation Requirements
- Professional installation is required because the UPS uses hardwired 230V input and output connections and a 40A input breaker. Installation, commissioning and battery servicing should be performed by suitably qualified electrical personnel in accordance with AS/NZS 3000 and the manufacturer's instructions.
Applications
- Server rooms and data centres
- Telecommunications and network infrastructure
- Industrial control and automation systems
- Point-of-sale systems
- Security and camera surveillance systems
- Telephone systems
- Critical computer and electronic equipment
Standards & Compliance
- AS 62040.1:2019 for UPS safety requirements
- AS/NZS 3000:2018 for permanent electrical installation, isolation, earthing and wiring requirements
Environmental Benefits
- Sealed lead-acid batteries can be recovered and recycled through appropriate battery recycling programmes
- 10-year design-life battery configuration can reduce replacement frequency and associated waste
- Online power conditioning can support reliable operation and reduce equipment damage caused by power disturbances
- Replaceable battery modules can extend the service life of the UPS system
Warranty Information
PSA Products Pty Ltd manufacturer warranty applies against manufacturing defects, with repair or replacement at PSA's discretion. Removal, reinstallation and transport costs are excluded; warranty duration should be confirmed at purchase.
Available Now
Available through ENDURO/PSS and authorised Australian electrical and power-equipment distributors; supplier availability should be confirmed before ordering.
UPS Sizing Calculator
This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
