8 Channel Network Video Recorder 4K HDMI PoE+ No HDD Ness

BRAND: Ness
SKU: 126-570
$369.50 List price: $492.70
+ −
30 Days Return Electricians Unlock Trade Access
Ness network video recorder features 8 channels, PoE+ ports and 4K HDMI output. Supplied without HDD. Ideal for CCTV installs.

Alternatively Known As: 8-Channel PoE NVR, 8-Port IP CCTV Recorder, 4K Network Video Recorder

Technical Specifications
  • Channel Capacity: 8 IP camera channels
  • Maximum Recording Resolution: Up to 16MP
  • Video Output: HDMI up to 3840 × 2160 and VGA
  • Video Compression: Smart H.265, H.265, Smart H.264 and H.264
  • Incoming Bandwidth: 160 Mbps
  • Outgoing Bandwidth: 160 Mbps
  • PoE Ports: 8 × 10/100 Mbps IEEE 802.3af/at ports
  • Network Interface: 1 × RJ45 Gigabit Ethernet port
  • Storage Interface: 2 × SATA ports
  • Maximum Storage: Up to 12TB per SATA drive
  • USB Ports: 1 × USB 2.0 front port and 1 × USB 3.0 rear port
  • AI Functions: Recorder-based SMD on 4 channels; camera-based analytics on 8 channels
  • Operating Temperature: -10°C to +55°C
  • Operating Humidity: Up to 95% RH, non-condensing
  • Power Supply: 52V DC, 2.3A
  • Hard Drive: Not included
  • Dimensions (H x L x W): 54mm x 375mm x 329.4mm
  • Weight: 2.5 kg
Key Features
  • 8-channel IP video recording for CCTV installations
  • Eight integrated PoE+ ports for direct camera connection and power
  • 4K HDMI display output
  • Supports recording resolutions up to 16MP
  • Smart H.265 compression helps reduce storage and network bandwidth requirements
  • Dual SATA bays for separately selected surveillance hard drives
  • ONVIF-compatible network surveillance architecture
  • Built-in smart motion detection and camera-based analytics support
  • Supplied without HDD for flexible storage selection
Professional Installation Requirements
  • Installation should be completed by a qualified CCTV or security systems installer. Any 230V AC mains connection should be undertaken in accordance with applicable Australian electrical requirements by an appropriately licensed person.
Applications
  • Residential CCTV systems
  • Small commercial security installations
  • Retail and office surveillance systems
  • Warehouses and light industrial sites
  • IP camera systems requiring integrated PoE power
  • Security systems requiring local 4K viewing and expandable SATA storage
Standards & Compliance
  • AS/NZS 62676 series is applicable to video surveillance system design, performance and application; product-specific conformity certification is not stated by the manufacturer.
Environmental Benefits
  • Smart H.265 compression can reduce network traffic and storage requirements compared with less efficient codecs.
  • Supplied without a hard drive, allowing installers to select an appropriately sized and energy-efficient surveillance drive and avoid unnecessary component replacement.
  • Dual SATA storage supports serviceable storage upgrades, which may extend the usable life of the recorder.
  • Long-term local recording and network management can reduce the need for continuously uploaded cloud video storage.
Warranty Information

Ness Corporation’s general warranty policy provides 3 years from the date of purchase for Ness-manufactured or supplied products, unless otherwise specified. Warranty claims are subject to Ness terms and conditions.

Available Now

Available through Ness Corporation and authorised Australian security distributors; stock status should be confirmed with the distributor.
