8 Channel Pentabrid DVR | 8 MP Resolution | AI Features & 1 SATA Support | Compact Design by Dahua Technology
8 Channel Pentabrid DVR with 8 MP resolution and AI features—ideal for residential and commercial surveillance. Built for efficient monitoring, with 1 SATA support and compact design for easy installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 8 Channel Pentabrid DVR | 8 MP Resolution | AI Features & 1 SATA Support | Compact Design by Dahua Technology
Brand: Dahua Technology
SKU: XVR5108HS-4KL-I3
Alternatively Known As: Dahua 8 Channel Pentabrid DVR, Dahua XVR 8ch 1 SATA, Dahua WizSense DVR, Dahua 4K Value Series Recorder
Technical Specifications
- Channels: 8 analog channels, up to 16 IP channels
- Video Input: HDCVI, AHD, TVI, CVBS, IP
- Max IP Camera Resolution: 8 MP per channel
- Bandwidth: 128 Mbps incoming
- Storage: 1 SATA HDD support
- Video Compression: Smart H.265+ and H.265 dual-stream
- AI Features: QuickPick 2.0, Privacy Protection, SMD Plus, Perimeter Protection, Face Recognition
- Form Factor: 1U compact design
- Dimensions (H x L x W): 45mm x 250mm x 300mm
- Weight: 1.5 kg
Key Features
- 8-channel Penta-brid support for HDCVI, AHD, TVI, CVBS, and IP video inputs
- Supports up to 16-channel IP camera input with up to 8 MP resolution per channel
- 2-channel QuickPick 2.0 for efficient target retrieval on analog channels
- 1-channel Privacy Protection with real-time face masking and restoration
- 8-channel SMD Plus for accurate human and vehicle alarm triggering
- 8-channel AI-powered perimeter protection with tripwire and intrusion detection
- 2-channel face recognition with face comparison capabilities
- AI Coding technology for storage and bandwidth savings
- Smart H.265+ and H.265 dual-stream video compression
- Supports 1 SATA HDD for storage
Professional Installation Requirements
- Professional installation by a qualified security system technician or electrician is recommended to ensure proper setup and compliance with electrical and safety standards.
Applications
- Residential security surveillance
- Commercial and retail store monitoring
- Industrial site surveillance
- Small to medium business security systems
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- AI Coding reduces storage and bandwidth usage, lowering energy consumption
- Supports efficient video compression with Smart H.265+ technology
Warranty Information
3 years warranty covering manufacturing defects and hardware failures.
Available Now
The Dahua XVR 8ch 1sata i3 Pentabrid NEW is available now for immediate purchase. Ideal for residential, commercial, and industrial surveillance applications.
