8 Port Gig Unmanaged PoE Switch | 120W Power | 6 KV Surge Protection | by Dicker Data
The 8 Port Gig Unmanaged PoE Switch is designed for seamless video data transmission, featuring 120W power and 6 KV surge protection. Ideal for small to medium business networks and IP camera systems, this switch supports IEEE 802.3 af & at standards, ensuring reliable power delivery and efficient data handling. With plug-and-play installation, it's perfect for security and surveillance applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 8 Port Gig Unmanaged PoE Switch | 120W Power | 6 KV Surge Protection | by Dicker Data
Brand: Dicker Data
SKU: DS-3E0510P-E
Alternatively Known As: Gigabit PoE Switch, Unmanaged PoE Network Switch, 8 Port PoE Switch, HIKVISION PoE Switch
Technical Specifications
- Layer 2 network switch for video data transmission
- 8 x 10/100/1000 Mbps Ethernet ports
- 1 x 10/100/1000 Mbps uplink Ethernet port
- 1 x 10/100/1000 Mbps uplink SFP port
- Supports IEEE 802.3, 802.3u, 802.3x, 802.3ab, 802.3z standards
- Supports IEEE 802.3 af & at PoE standards
- Store-and-forward switching method
- 6 KV high surge protection
- Dimensions (H x L x W): 45mm x 140mm x 220mm
- Weight: 1.2 kg
Key Features
- 8 x 10/100/1000 Mbps Ethernet ports with PoE support
- 1 x 10/100/1000 Mbps uplink Ethernet port
- 1 x 10/100/1000 Mbps uplink SFP port for fiber connectivity
- Supports IEEE 802.3 af & at high PoE power supply
- Store-and-forward switching for efficient data handling
- 6 KV high surge protection for device safety
- Plug and play for easy installation
Professional Installation Requirements
- Installation by a qualified network technician or electrician is recommended to ensure proper setup and compliance with electrical standards.
Applications
- Video data transmission for security and surveillance networks
- Small to medium business network setups requiring PoE support
- IP camera systems and network video recorders
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Energy-efficient design reduces power consumption during operation
- Supports PoE to reduce the need for additional power cables and adapters
Warranty Information
2 years warranty from the manufacturer covering defects and hardware failures.
Available Now
The HIKVISION Transmission 3E0510P-E 8 Port Gig Unmanaged PoE Switch is available for immediate purchase, ideal for security and surveillance network applications.
