8W Low-Profile LED Tri-Colour Downlight | Dimmable Driver | IP54 Rated | by atom
The 8W low-profile LED tri-colour downlight offers versatile lighting with a dimmable driver, perfect for both residential and commercial spaces. With an IP54 rating for moisture resistance and a high efficiency of up to 130 lm/W, this downlight is designed for recessed ceiling installations, providing adjustable colour temperatures of warm white, cool white, and daylight to suit any environment.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: LED tri-colour downlight, dimmable LED downlight, recessed LED ceiling light, 8W LED spotlight
Technical Specifications
- Total System Efficiency: up to 130 lm/W
- IP Rating: IP54 front face only
- IC Rating: IC-4 for insulation coverage
- Colour Rendering Index (CRI): >80
- Beam Angle: 100°
- LED Lifetime: >60,000 hours (TM-21 tested 10,000 hours)
- Input Voltage: 230Vac (-6%/+10%)
- Power Factor: 0.9
- Input Current: 0.05 A
- Driver Type: Dimmable phase cut, constant current 110 mA
- Flex & Plug Length: 600 mm
- Operating Temperature Range: -20 to 40 °C
- Macadam Steps: 5-step MacAdam ellipse
- Dimensions (H x L x W): 50mm x 90mm x 90mm
- Weight: 0.3 kg
Key Features
- Tri-colour CCT configuration with warm white (3000K), cool white (4000K), and daylight (5700K)
- Dimmable phase cut driver included for adjustable lighting
- High system efficiency up to 130 lm/W
- IP54 rated front face for moisture resistance
- IC-4 rated for safe insulation coverage
- Long LED lifetime greater than 60,000 hours
- Fixed adjustability with white PA6 body and polycarbonate diffuser
- Power factor of 0.9 and input voltage range 216-253Vac
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended to ensure compliance with electrical safety standards and correct dimmable driver setup.
Applications
- Residential lighting: living rooms, kitchens, bedrooms
- Commercial lighting: offices, retail spaces, hospitality
- Recessed ceiling installations requiring adjustable colour temperature
Standards & Compliance
- AS/NZS 60598.1 – Luminaires General Requirements
- AS/NZS 60598.2.1 – Fixed General Purpose Luminaires
- AS/NZS 61347.1 – Lamp Control Gear General and Safety Requirements
- AS/NZS 61347.2.13 – Particular Requirements for LED Modules
- AS CISPR 15 – Limits and Methods of Measurement of Radio Disturbance Characteristics of Electrical Lighting and Similar Equipment
Environmental Benefits
- High luminous efficacy reduces energy consumption
- Long LED lifetime minimizes waste and replacement frequency
- Dimmable driver allows energy savings through adjustable light output
Warranty Information
Standard 3 years return-to-base warranty for domestic use. VIP warranty offers 2 years onsite plus 3 years return-to-base (total 5 years) for registered users under specific terms.
Available Now
The Atom 8W low-profile LED tri-colour downlight with dimmable driver is available for immediate purchase, ideal for residential and commercial recessed lighting applications.
Lighting Requirement Calculator
This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
