90 Degree Surface Socket IP67 | 63A Current Rating | 415V Three Phase | 3P+E Configuration | by Tobin
The 90 Degree Surface Socket IP67 is designed for robust industrial and commercial power distribution, featuring a 63A current rating and 415V voltage for three-phase applications. With an IP67 rating, it ensures protection against dust and water ingress, making it ideal for outdoor and harsh environments. This surface mount design allows for space-saving installation, ensuring safety with its 3P+E configuration.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 90 Degree Surface Socket IP67 | 63A Current Rating | 415V Three Phase | 3P+E Configuration | by Tobin
Brand: Tobin
SKU: GW63526
Alternatively Known As: Industrial Surface Socket, IEC 309 Surface Socket, 3 Phase Surface Socket, IP67 Industrial Socket
Technical Specifications
- Current Rating: 63A
- Voltage Rating: 415V
- Poles: 3P+E (Three Phase plus Earth)
- Ingress Protection: IP67
- Mounting Type: Surface mount
- Angle: 90 degrees
- Standards Compliance: IEC 309
- Dimensions (H x L x W): 150mm x 100mm x 120mm
- Weight: 1.5 kg
Key Features
- IP67 rated for dust and water ingress protection
- 90 degree surface mount design for space-saving installation
- 63A current rating suitable for high power industrial applications
- 415V voltage rating for three-phase power supply
- 3P+E configuration ensuring safety with earth connection
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure compliance with electrical safety standards and proper connection.
Applications
- Industrial: Heavy machinery and equipment connections
- Commercial: Warehouses and factories requiring robust power connections
- Outdoor: Weatherproof power socket for harsh environments
Standards & Compliance
- AS/NZS 3123 – Industrial Plugs and Socket-Outlets
Environmental Benefits
- Durable construction reduces replacement frequency and waste
- IP67 rating prevents ingress of contaminants, reducing maintenance and environmental impact
Warranty Information
3 years warranty covering manufacturing defects and performance issues.
Available Now
The Tobin 90 Degree Surface Socket IP67 63A 415V 3P+E is available for immediate purchase, ideal for industrial and commercial power distribution applications.
