90Deg Surface Socket IP67 | 32A 415V | 3P+E Configuration | Waterproof Design | by Tobin
The 90Deg Surface Socket IP67 is designed for reliable electrical connections in industrial and commercial settings. Rated at 32A and 415V, this socket features a 90-degree surface mount design for space-saving installation and is IP67 rated for dust-tight and waterproof protection. Ideal for heavy machinery and outdoor applications, it ensures secure connections in harsh environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 90Deg Surface Socket IP67 | 32A 415V | 3P+E Configuration | Waterproof Design | by Tobin
Brand: Tobin
SKU: GW62515
Alternatively Known As: Industrial Surface Socket, IEC 309 Surface Socket, 32 Amp Surface Socket, IP67 Industrial Socket
Technical Specifications
- Current Rating: 32 Amps
- Voltage Rating: 415 Volts
- Poles: 3 Pole plus Earth (3P+E)
- Ingress Protection: IP67 - dust tight and waterproof
- Mounting Type: Surface mount with 90-degree orientation
- Standards Compliance: IEC 309
- Dimensions (H x L x W): 120mm x 90mm x 100mm
- Weight: 1.5 kg
Key Features
- Rated at 32A current and 415V voltage
- 90-degree surface mount design for space-saving installation
- IP67 rated for dust-tight and waterproof protection
- 3 Pole plus Earth (3P+E) configuration for secure electrical connections
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure compliance with electrical safety standards and proper IP67 sealing.
Applications
- Industrial: Heavy machinery and equipment connections
- Commercial: Warehouses, factories, and workshops
- Outdoor: Harsh environments requiring waterproof electrical connections
Standards & Compliance
- AS/NZS 3123 – Industrial Plugs and Socket-Outlets
Environmental Benefits
- Durable IP67 rating reduces need for frequent replacements, minimizing waste
- Designed for energy-efficient electrical connections reducing power loss
Warranty Information
3 years warranty against manufacturing defects.
Available Now
The Tobin 90Deg Surface Socket IP67 32A 415V 3P+E is available for immediate purchase, ideal for industrial and commercial electrical installations requiring robust and waterproof connections.
