A9 iC60H3 3P+Ns C Curve 16A 30mA A RCBO | High Breaking Capacity | DIN Rail Mount | by Clipsal
The A9 iC60H3 3P+Ns C Curve 16A 30mA A RCBO combines MCB and RCD functionality in a single device, making it perfect for commercial and residential switchboards. With a high breaking capacity and quick DIN rail mounting, it provides reliable protection against overloads, short circuits, and earth leakage, ensuring safety in electrical distribution systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: A9 iC60H3 3P+Ns C Curve 16A 30mA A RCBO | High Breaking Capacity | DIN Rail Mount | by Clipsal
Brand: Clipsal
SKU: SCHA9DC1916
Alternatively Known As: Clipsal RCBO, 3 Pole RCBO, 16A RCBO, A9 iC60H3 RCBO, SCHA9DC1916, Residual Current Circuit Breaker with Overcurrent Protection
Technical Specifications
- Rated current: 16A
- Poles: 3P+Ns (3 pole + neutral switched)
- Tripping curve: C
- Residual current: 30mA (Type A)
- Rated voltage: 400V AC
- Breaking capacity: 6kA
- Mounting: DIN rail
- Standards: IEC/EN 61009-1
- Dimensions (H x L x W): 85mm x 78mm x 72mm
- Weight: 0.45 kg
Key Features
- Combined MCB and RCD in a single device for space-saving installation
- 3 pole + neutral switched (3P+Ns) configuration
- C Curve tripping characteristic for general purpose protection
- Rated current: 16A
- Residual current sensitivity: 30mA (Type A)
- High breaking capacity for reliable protection
- Quick and easy DIN rail mounting
Professional Installation Requirements
- Must be installed by a licensed electrician in accordance with Australian standards and local regulations.
Applications
- Commercial and industrial electrical distribution boards
- Residential switchboards for enhanced circuit protection
- Protection of lighting and power circuits against overload, short circuit, and earth leakage
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Reduces risk of electrical fires and faults, enhancing building safety
- Long operational life reduces replacement frequency and waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
Available for immediate purchase. Ideal for use in commercial, industrial, and residential switchboards requiring reliable circuit and earth leakage protection.
