A9 iC60H3 3P+Ns C Curve 20A 30mA A RCBO | High Breaking Capacity | DIN Rail Mount | by Clipsal
The A9 iC60H3 3P+Ns C Curve 20A 30mA A RCBO is designed for reliable circuit and residual current protection in residential and commercial applications. With a high breaking capacity of 6000A and a compact DIN rail mount design, it ensures safety against overloads and earth leakage. Ideal for electricians and installers, this device meets AS/NZS standards for electrical installations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: A9 iC60H3 3P+Ns C Curve 20A 30mA A RCBO | High Breaking Capacity | DIN Rail Mount | by Clipsal
Brand: Clipsal
SKU: SCHA9DC1920
Alternatively Known As: Clipsal RCBO, 3P+N RCBO, 20A RCBO, A9 iC60H3 RCBO, SCHA9DC1920, Residual Current Circuit Breaker with Overcurrent Protection
Technical Specifications
- Rated current: 20A
- Poles: 3P+Ns (3 pole + neutral switched)
- Tripping curve: C Curve
- Residual current sensitivity: 30mA (Type A)
- Rated voltage: 400V AC
- Breaking capacity: 6000A
- Mounting: DIN rail
- Standards: IEC/EN 61009-1
- Frequency: 50/60Hz
- Dimensions (H x L x W): 85mm x 78mm x 72mm
- Weight: 0.45 kg
Key Features
- Combined circuit breaker and residual current device (RCBO)
- 3 pole + neutral switched (3P+Ns) configuration
- C Curve tripping characteristic for general applications
- 20A rated current
- 30mA residual current sensitivity (Type A)
- Provides protection against overloads, short circuits, and earth leakage
- Compact DIN rail mount design
- High breaking capacity
Professional Installation Requirements
- Installation must be carried out by a licensed electrician in accordance with AS/NZS 3000 wiring rules and local regulations.
Applications
- Residential and commercial distribution boards
- Industrial switchboards
- Protection of lighting and power circuits
- Environments requiring combined circuit protection and residual current protection
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enhances electrical safety, reducing risk of fire and electrical hazards
- Supports energy-efficient circuit management by preventing faults
Warranty Information
12 months manufacturer's warranty.
Available Now
The Clipsal A9 iC60H3 3P+Ns C Curve 20A 30mA A RCBO (SCHA9DC1920) is available for immediate purchase. Ideal for use in residential, commercial, and industrial switchboards requiring reliable circuit and residual current protection.
