A9 iC60H3 3P+Ns C Curve 50A 30mA A RCBO | Compact DIN Rail Mount | Earth Leakage & Overload Protection | by Clipsal
The A9 iC60H3 3P+Ns C Curve 50A 30mA A RCBO is designed for reliable circuit protection in commercial and residential applications. With a compact DIN rail mount design, it combines residual current device (RCD) and miniature circuit breaker (MCB) functionalities, ensuring safety against earth leakage and overload. Ideal for enhancing electrical safety in distribution boards and switchboards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: A9 iC60H3 3P+Ns C Curve 50A 30mA A RCBO | Compact DIN Rail Mount | Earth Leakage & Overload Protection | by Clipsal
Brand: Clipsal
SKU: SCHA9DC1950
Alternatively Known As: Clipsal RCBO, 3 Phase RCBO, 50A RCBO, A9 iC60H3 RCBO, SCHA9DC1950, Residual Current Circuit Breaker with Overcurrent Protection
Technical Specifications
- Rated current: 50A
- Poles: 3P+Ns (3 phase + neutral switched)
- Tripping curve: C
- Residual current sensitivity: 30mA (Type A)
- Rated voltage: 400V AC
- Breaking capacity: 6kA
- Mounting: DIN rail
- Test button: Yes
- Standards: IEC/EN 61009-1
- Dimensions (H x L x W): 85mm x 78mm x 72mm
- Weight: 0.45 kg
Key Features
- Combined residual current device (RCD) and miniature circuit breaker (MCB) in one unit
- 3 pole + neutral switched (3P+Ns) configuration
- C Curve tripping characteristic for general applications
- Rated current: 50A
- Residual current sensitivity: 30mA (Type A)
- Provides protection against earth leakage, overload, and short circuit
- Compact DIN rail mount design
- Test button for regular safety checks
Professional Installation Requirements
- Must be installed by a licensed electrician in accordance with AS/NZS 3000 and local regulations.
Applications
- Commercial and industrial electrical distribution boards
- Residential switchboards for enhanced circuit protection
- Protection of lighting, power, and socket outlet circuits
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enhances electrical safety, reducing risk of fire and electrical hazards
- Long operational life reduces replacement frequency and waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal A9 iC60H3 3P+Ns C Curve 50A 30mA A RCBO (SCHA9DC1950) is available for immediate purchase. Ideal for commercial and residential switchboards requiring reliable circuit and earth leakage protection.
