A9 iC60H3 3P+Ns D Curve RCBO | 32A Rated Current | 30mA Sensitivity | High Breaking Capacity | @Pack of 1 | by Clipsal
The A9 iC60H3 3P+Ns D Curve RCBO is designed for advanced circuit protection, featuring a 32A rated current and 30mA residual current sensitivity. Ideal for commercial and residential applications, this device combines MCB and RCD functions in a compact DIN rail mount design, ensuring safety against overloads and earth leakage faults. With a high breaking capacity and a test button for regular checks, it’s a reliable choice for any switchboard.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: A9 iC60H3 3P+Ns D Curve RCBO | 32A Rated Current | 30mA Sensitivity | High Breaking Capacity | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHA9DD1932
Alternatively Known As: Clipsal RCBO, 3P+N RCBO, 32A D Curve RCBO, Residual Current Circuit Breaker with Overcurrent, SCHA9DD1932
Technical Specifications
- Rated current: 32A
- Poles: 3P+Ns (3 pole + neutral switched)
- Tripping curve: D
- Residual current: 30mA (Type A)
- Breaking capacity: 10kA
- Mounting: DIN rail
- Test button: Yes
- Voltage: 400V AC
- Frequency: 50/60Hz
- Dimensions (H x L x W): 85mm x 78mm x 72mm
- Weight: 0.45 kg
Key Features
- Combined MCB and RCD in a single device
- 3 pole + neutral switched (3P+Ns) configuration
- D Curve for high inrush current protection
- 32A rated current
- 30mA residual current sensitivity (Type A)
- High breaking capacity
- Compact DIN rail mount design
- Test button for regular safety checks
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 and local regulations.
Applications
- Commercial and industrial switchboards
- Residential distribution boards
- Protection of circuits against overload, short-circuit, and earth leakage faults
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 61009 – Residual current operated circuit-breakers with integral overcurrent protection
Environmental Benefits
- Enhances electrical safety, reducing risk of fire and electrical hazards.
- Long operational life reduces replacement frequency and waste.
Warranty Information
12 months manufacturer's warranty.
Available Now
Available for immediate purchase. Ideal for commercial, industrial, and residential switchboard applications requiring advanced circuit and earth leakage protection.
