Absolute Encoder 25mm Square Flange | NEMA 4 Rated | 256 PPR Gray Code | by Allen-Bradley
The Absolute Encoder 25mm Square Flange is designed for precise position feedback in industrial automation. With a NEMA 4 rating for dust and water protection, it operates on an 8-24 V DC unregulated power supply and features a Gray code output with 256 pulses per revolution. Ideal for robotics and manufacturing equipment, this encoder ensures reliable performance in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Type: Absolute encoder
- Size: 25mm square flange
- Shaft diameter: 3/8 inch
- Output type: NPN open collector
- Voltage: 8-24 V DC unregulated
- Pulses per revolution: 256 PPR
- Code: Gray code
- Connector: Axial connector with mate
- Protection rating: NEMA 4
- Dimensions (H x L x W): 25mm x 60mm x 25mm
- Weight: 0.2 kg
Key Features
- Absolute encoder providing precise position feedback
- NEMA 4 rated for protection against dust and water
- Square flange design with 3/8 inch shaft
- Gray code output with 256 pulses per revolution (PPR)
- Axial connector with mating plug included
- Operates on 8-24 V DC unregulated power supply
- NPN open collector output, 24 V DC max
- No latch feature
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper wiring and operation.
Applications
- Industrial automation and control systems
- Robotics and machinery requiring precise position feedback
- Manufacturing equipment with rotary position sensing
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable NEMA 4 rating reduces need for frequent replacements, minimizing waste
- Low power consumption with 8-24 V DC operation
Warranty Information
Radwell 2-year warranty included; factory warranty does not apply.
Available Now
The Allen-Bradley 845DSJDZ25AGCW4 Absolute Encoder is available for immediate purchase, ideal for industrial automation and precise position sensing applications.
