Absolute Rotary Encoder SKM36-HVA0-K02 | High Accuracy ±120″ | 16,777,216 Steps | IP50 Rated | by SICK
The Absolute Rotary Encoder SKM36-HVA0-K02 delivers high precision with ±120″ accuracy and 16,777,216 total steps, making it ideal for industrial automation and robotics. Designed for reliable performance in safety-critical applications, it features a robust IP50 enclosure and operates at speeds up to 9,000 min⁻¹. With a long service life and low current consumption, this encoder is perfect for demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Absolute Rotary Encoder SKM36-HVA0-K02 | High Accuracy ±120″ | 16,777,216 Steps | IP50 Rated | by SICK
Brand: SICK
SKU: 1035601
Alternatively Known As: Absolute rotary encoder, HIPERFACE encoder, position encoder, rotary position sensor
Technical Specifications
- MTTFD: 205 years (EN ISO 13849)
- Sine/cosine periods per revolution: 128
- Number of absolute ascertainable revolutions: 4,096
- Total number of steps: 16,777,216
- Measuring step: 2.5 ″ with 12-bit interpolation
- Integral non-linearity: ±120 ″
- Operating speed: up to 9,000 min⁻¹
- Supply voltage: 7 V DC to 12 V DC (recommended 8 V DC)
- Current consumption: 60 mA
- Output frequency for sine/cosine signals: ≤ 65 kHz
- Connection type: Male connector, M12, 8-pin, radial
- Operating temperature range: –20 °C to +100 °C
- Enclosure rating: IP50 with mating plug inserted
- Moment of inertia of rotor: 6 gcm²
- Operating torque: 0.6 Ncm
- Start up torque: +0.9 Ncm
- Permissible shaft loading: 10 N radial, 5 N axial
- Life of ball bearings: 2.0 x 10^9 revolutions
- Dimensions (H x L x W): 36mm x 60mm x 36mm
- Weight: 0.1 kg
Key Features
- High system accuracy of ±120 ″
- Absolute position measurement with 16,777,216 total steps
- Binary code output with HIPERFACE® communication interface
- Solid shaft with servo-/face mount flange
- Operating speed up to 9,000 min⁻¹
- Robust design with IP50 enclosure rating
- Wide operating temperature range from –20 °C to +100 °C
- Mean time to dangerous failure (MTTFD) of 205 years according to EN ISO 13849
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with encoder integration and electrical connections to ensure proper operation and safety compliance.
Applications
- Industrial automation for precise position measurement
- Servo motor feedback systems
- Robotics and motion control
- Machine tool positioning
- Safety-related applications requiring high reliability
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Long service life reduces waste and replacement frequency
- Low current consumption (60 mA) contributes to energy efficiency
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK SKM36-HVA0-K02 Absolute Encoder is available for immediate purchase, ideal for industrial automation and safety-critical applications requiring precise position feedback.
