Access Control Reader | IP66 Rated | IC Card Support & Anti-Tampering Alarm | Dahua
Access control reader with IP66 rating and IC card support—ideal for enhancing security in commercial and residential buildings. Built for reliable outdoor use, featuring an anti-tampering alarm and dual unlock methods for added convenience.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Access Control Reader | IP66 Rated | IC Card Support & Anti-Tampering Alarm | Dahua
Brand: Dahua Technology
SKU: ASR2101A
Alternatively Known As: Dahua Access Reader, ASR2101A RFID Reader, Dahua Contactless Card Reader
Technical Specifications
- Material: PC and acrylic panel
- Ingress Protection: IP66
- Card Type Supported: IC card (Mifare card)
- Unlock Methods: Card and password
- Communication Interfaces: RS-485, Wiegand 34 (configurable to Wiegand 26)
- Indicators: Buzzer and LED indicator
- Security Features: Anti-tampering alarm, built-in watchdog
- Protection: Overcurrent and overvoltage on connection ports
- Dimensions (H x L x W): 150mm x 25mm x 90mm
- Weight: 0.3 kg
Key Features
- PC material and acrylic panel with IP66 rating for indoor and outdoor use
- Supports contactless recognition of IC card (Mifare card)
- Supports card and password unlock
- Communication via RS-485 and configurable Wiegand 34 or Wiegand 26
- Buzzer and indicator prompt for user feedback
- Anti-tampering alarm for enhanced security
- Built-in watchdog for detecting and recovering from abnormal operation
- Overcurrent and overvoltage protection on all connection ports
Professional Installation Requirements
- Professional installation by a qualified security systems technician or electrician is recommended to ensure proper configuration and compliance with safety standards.
Applications
- Access control for commercial buildings
- Security systems for residential complexes
- Industrial facility entry management
- Indoor and outdoor access points
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable IP66 rated design reduces need for frequent replacements
- Low power consumption for energy efficiency
Warranty Information
1 year warranty covering manufacturing defects and hardware malfunctions.
Available Now
The Dahua ASR2101A Access Control Reader is available now for immediate purchase. Ideal for enhancing security in commercial, residential, and industrial access control systems.
