AEx Emergency Stop Turn to Release | IP66 Rated | Mushroom Head Design | ATEX/IECEx Certified | @Pack of 1 | by Clipsal
The AEx Emergency Stop Turn to Release is designed for hazardous environments, featuring a robust mushroom head actuator for quick emergency shutdowns. With an IP66 rating for dust and water protection, this emergency stop button is ideal for industrial machinery and process automation safety systems, ensuring compliance with safety standards in explosive atmospheres.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: AEx Emergency Stop Turn to Release | IP66 Rated | Mushroom Head Design | ATEX/IECEx Certified | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHXB4BS8445GEX
Alternatively Known As: Explosion Proof Emergency Stop, Hazardous Area E-Stop, Clipsal Emergency Stop Button, Turn to Release E-Stop
Technical Specifications
- Actuator type: Emergency stop, turn to release
- Head type: Mushroom, red
- Enclosure rating: IP66
- Material: High-impact plastic and metal
- Mounting diameter: 22mm
- Contact configuration: 1 NC (normally closed)
- Explosion protection: Suitable for hazardous areas (ATEX/IECEx certified)
- Operating temperature: -40°C to +70°C
- Dimensions (H x L x W): 40mm x 60mm x 40mm
- Weight: 0.25 kg
Key Features
- Emergency stop actuator with turn-to-release mechanism
- Robust design for hazardous (explosive) environments
- Maintained function for safety compliance
- High visibility red mushroom head
- IP66 rated for dust and water protection
Professional Installation Requirements
- Installation must be performed by a licensed electrician familiar with hazardous area requirements and local regulations.
Applications
- Industrial machinery emergency stop control
- Hazardous area equipment shutdown
- Manufacturing plants
- Process automation safety systems
Standards & Compliance
- Complies with AS/NZS 60947 for low-voltage switchgear and controlgear
- Complies with AS/NZS 60035 for electrical equipment in explosive atmospheres
Environmental Benefits
- Enhances workplace safety, reducing risk of environmental incidents due to uncontrolled machinery.
- Durable construction minimizes replacement frequency and waste.
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal AEx Emergency Stop Turn to Release (SCHXB4BS8445GEX) is available for immediate purchase. Ideal for industrial and hazardous area emergency stop applications.
