Airbus EC 200 Exhaust Fan Body Only White Ventair
Airbus EC 200 Energy Efficient Exhaust Fan Body Only Compatible with Any Airbus 200 Fascias by Ventair
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Airbus EC 200 Exhaust Fan Body, Ventair PVPXEC200 Motor Body, 200mm Ceiling Exhaust Fan Motor
Technical Specifications
- Model: PVPXEC200
- Colour: White
- Motor Type: Energy-efficient three-speed EC motor
- Operating Modes: Boost, Run and continuous 24/7 trickle ventilation
- Motor Power: Boost 24 W, Run 14 W, 24/7 3 W
- Air Delivery: Boost 245 m³/h, Run 180 m³/h, 24/7 65 m³/h
- Noise Level: Boost 37 dB(A), Run 30 dB(A), 24/7 28 dB(A)
- Duct Outlet: 100 mm side outlet
- Cut-Out Size: 240 mm diameter
- Ingress Protection: IPX4
- Power Input: 220–240 V AC, 50 Hz
- Installation Connection: Plug and lead
- Included Control: Wireless wall controller
- Compatibility: Any Airbus 200 fascia
- Mounting: Ceiling
- Motor Bearings: Ball bearing
- Draft Stopper: Included
- Dimensions (H x L x W): 170mm x 265mm x 265mm
- Weight: 1.5 kg
Key Features
- Motor body supplied without a fascia
- Compatible with any Ventair Airbus 200 fascia
- Continuous 24/7 trickle extraction for stale and moist air reduction
- Three operating speeds for low-energy continuous ventilation or rapid extraction
- Boost mode provides up to 245 m³/h airflow
- Low 3 W power consumption in continuous 24/7 mode
- Designed for extended ducting applications
- Wireless wall controller included
- IPX4-rated construction for damp-area applications
Professional Installation Requirements
- Installation and electrical connection must be completed by a licensed electrician in accordance with the installation instructions and AS/NZS 3000. Exhaust air should be ducted to outdoor air in accordance with applicable building requirements.
Applications
- Bathroom ventilation
- Powder room ventilation
- Toilet ventilation
- Laundry ventilation
- Residential continuous ventilation
- Replacement or new installation using an Airbus 200 fascia
Standards & Compliance
- AS/NZS 60335.2.80:2025 – applicable safety requirements for household and similar electric fans
- AS/NZS 3000 – applicable requirements for electrical installation and connection
Environmental Benefits
- Energy-efficient EC motor uses only 3 W in continuous 24/7 mode
- Continuous low-energy extraction can help reduce moisture-related indoor air issues
- Long-life ball bearing motor helps reduce replacement frequency and material waste
- Lower operating power can reduce electricity consumption compared with conventional exhaust fan motors
Warranty Information
Five-year replacement-only warranty covering manufacturing faults or defects for domestic use. Commercial use is covered by a one-year warranty. Warranty conditions require installation by a licensed electrical contractor where applicable.
Available Now
Available through authorised Ventair distributors in Australia.
