Airbus EC 500 Exhaust Fan Body Only White Ventair
Airbus EC 500 Energy Efficient Exhaust Fan Body Only Compatible with Any Airbus 250 Fascias by Ventair
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Ventair Airbus EC 500 Motor Body, PVPXEC500 Exhaust Fan Body, Airbus EC 500 Side-Ducted Exhaust Fan
Technical Specifications
- Model Number: PVPXEC500
- Colour: White
- Motor Type: Three-speed energy-efficient EC motor
- Motor Bearings: Ball bearing
- Air Delivery: Boost 510 m³/h; Run 380 m³/h; 24/7 70 m³/h
- Motor Power: Boost 80 W; Run 35 W; 24/7 3 W
- Noise Level: Boost 44 dB(A); Run 40 dB(A); 24/7 21 dB(A)
- Duct Outlet: 150 mm side outlet
- Cut-Out Size: 300 mm
- Minimum Installation Depth: 220 mm
- Power Input: 220–240 V AC, 50 Hz
- Ingress Protection: IPX4
- Installation Connection: Plug and lead
- Controller: Wireless wall controller included
- Backdraft Stopper: Included
- Fascia Compatibility: Compatible with any Airbus 250 fascia
- Dimensions (H x L x W): 195mm x 326mm x 326mm
- Weight: 3 kg
Key Features
- Body-only configuration allows selection of a compatible Airbus 250 fascia
- Three operating modes for boost, standard extraction and continuous 24/7 ventilation
- Energy-efficient EC motor designed for low operating costs
- Continuous trickle ventilation helps reduce stale and moist air
- Side-ducted design with 150 mm outlet
- Wireless wall controller included
- Ball bearing motor for reliable operation
- Suitable for ceiling-mounted installation
Professional Installation Requirements
- Installation should be completed by a licensed electrician in accordance with the instruction manual and applicable Australian electrical installation requirements. The exhaust system should be ducted and discharged to outdoor air where required by the National Construction Code.
Applications
- Bathrooms and ensuites
- Large open bathrooms
- Residential ceiling ventilation
- Continuous moisture and stale-air control
Standards & Compliance
- AS/NZS 60335.2.80 – safety requirements for household and similar electric fans
Environmental Benefits
- Three-watt continuous 24/7 mode helps reduce energy consumption during ongoing ventilation
- Energy-efficient EC motor can reduce operating energy compared with conventional exhaust fan motors
- Continuous moisture control may help reduce mould-related maintenance and premature replacement of building finishes
- Long-life ball bearing motor design can help reduce replacement frequency and product waste
Warranty Information
Five-year manufacturer warranty for domestic use; one-year warranty for commercial use. Warranty conditions require installation by a licensed electrical contractor where applicable and installation in accordance with the product instructions.
Available Now
Available through authorised Ventair distributors in Australia.
