AJAX Internal Battery NB | 7.2V Non-Rechargeable | 95Ah Capacity | Molex Connector | by AJAX

BRAND: AJAX
SKU: 121874.313.NC
$263.20 List price: $318.50
+ −
30 Days Return Delivery Options
The AJAX Internal Battery NB is a 7.2V non-rechargeable lithium thionyl chloride battery designed for reliable power supply in off-grid security systems. With a robust capacity of 95Ah and a maximum load current of 700mA, it ensures long-term operation and compliance with safety standards. Ideal for use in Hub BP Jeweller systems, this battery supports sustainable security solutions with minimal replacements.

Product Name/Title: AJAX Internal Battery NB | 7.2V Non-Rechargeable | 95Ah Capacity | Molex Connector | by AJAX

Brand: AJAX

SKU: 121874.313.NC

Alternatively Known As: AJAX Hub BP Jeweller Internal Battery, 7.2V Lithium Battery, Security System Battery Pack

Technical Specifications
  • Battery type: 10 × ER34615, Non-rechargeable lithium thionyl chloride with HPC-1520 pulse capacitor
  • Nominal voltage: 7.2 V⎓
  • Capacity: 95 Ah
  • Maximum load current: 700 mA
  • End-of-life battery voltage: 4 V⎓
  • Battery connector type: Molex 2139-2
  • Operating temperature range: −10 °C to +40 °C
  • Operating humidity: up to 75%
  • Dimensions (H x L x W): 105mm x 135mm x 65mm
  • Weight: 0.99 kg
Key Features
  • Non-rechargeable lithium thionyl chloride battery with HPC-1520 pulse capacitor
  • Nominal voltage of 7.2 V⎓ and capacity of 95 Ah
  • Maximum load current of 700 mA
  • Operating temperature range from −10 °C to +40 °C
  • Operating humidity up to 75%
  • Battery connector type: Molex 2139-2
Professional Installation Requirements
  • Installation by a qualified technician is recommended to ensure proper connection and safety compliance.
Applications
  • Power supply for Hub BP Jeweller in off-grid security systems
  • Suitable for long-term and reliable operation in security hubs
Standards & Compliance
  • Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
  • Non-rechargeable battery designed for long-term use reducing frequent replacements
  • Reliable power source supports sustainable security system operation
Warranty Information

24 months warranty against manufacturing defects.

Available Now

The AJAX Internal Battery NB 7.2V 95Ah is available for immediate purchase, ideal for off-grid security system applications.
