Trade Discount 17%
AJAX MotionProtect Plus Fibra Black | Dual Sensor Technology | 12m Detection Range | IP50 & IK04 Rated | by AJAX
AJAX MotionProtect Plus Fibra Black is designed for reliable motion detection with dual sensor technology, featuring a PIR sensor and K-band microwave sensor for enhanced accuracy. With a detection range of up to 12 meters and adjustable sensitivity, it's perfect for residential, commercial, and industrial security systems. This device operates effectively in temperatures from -10°C to +40°C, ensuring optimal performance in various environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: AJAX MotionProtect Plus Fibra Black | Dual Sensor Technology | 12m Detection Range | IP50 & IK04 Rated | by AJAX
Brand: AJAX
SKU: 44407.02.BL1
Alternatively Known As: AJAX Motion Protect Plus Fibra, AJAX Motion Detector Fibra Black, AJAX PIR Microwave Sensor, AJAX Wired Motion Sensor
Technical Specifications
- Sensing Element: 1 × PIR sensor, 1 × K-band microwave sensor
- Motion Detection Distance: Up to 12 meters (installed at 2.4 meters height)
- Motion Detection Angles: Horizontal — 88.5°
- Motion Detection Speed: From 0.3 to 2.0 m/s
- Sensitivity: 3 levels
- Pet Immunity: Up to 20 kg, up to 50 cm height
- Temperature Compensation: Effective detection within −10°C to +40°C
- Power Supply: Fibra line power supply (5−30 V⎓, up to 25 mW)
- Line Connection: 4-core cable
- Fibra Line Length: Up to 2,000 meters (using U/UTP cat.5 twisted pair)
- Operating Temperature Range: From −10 °C to +40 °C
- Operating Humidity: Up to 75%
- Protection Class: IP50, IK04
- Dimensions (H x L x W): 110mm x 50mm x 65mm
- Weight: 0.086 kg
Key Features
- Dual sensor technology with 1 × PIR sensor and 1 × K-band microwave sensor for enhanced detection accuracy
- Motion detection distance up to 12 meters when installed at 2.4 meters height
- Horizontal detection angle of 88.5°
- Adjustable sensitivity with 3 levels
- Pet immunity for animals up to 20 kg and 50 cm height
- Temperature compensation for effective detection between −10°C to +40°C
- Powered via Fibra line power supply (5−30 V⎓, up to 25 mW)
- Supports line connection via 4-core cable
- Fibra line length support up to 2,000 meters using U/UTP cat.5 twisted pair
- Protection class IP50 and IK04 for dust resistance and impact protection
Professional Installation Requirements
- Professional installation by a qualified security system technician or electrician is recommended to ensure proper integration with AJAX Fibra systems and optimal performance.
Applications
- Residential security systems
- Commercial security installations
- Industrial premises requiring motion detection
- Integration with AJAX Fibra wired security systems
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Low power consumption with efficient Fibra line power supply
- Durable design reduces waste and replacement frequency
Warranty Information
24 months warranty provided by the manufacturer.
Available Now
The AJAX MotionProtect Plus Fibra Black 2YR is available for immediate purchase, ideal for enhancing wired security systems in residential, commercial, and industrial applications.
