AJAX MultiTransmitter Black | 18 Wired Zones | Wireless Connection Up to 2000m | Instant Alarm Delivery | by Dicker Data
AJAX MultiTransmitter Black is designed to integrate existing wired alarm systems with modern wireless security solutions. Supporting 18 wired zones and various connection types, it ensures seamless communication with your security hub up to 2000 meters away. Ideal for both residential and commercial applications, this module offers instant alarm delivery and backup power for enhanced reliability.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: AJAX MultiTransmitter Black | 18 Wired Zones | Wireless Connection Up to 2000m | Instant Alarm Delivery | by Dicker Data
Brand: Dicker Data
SKU: 30661.62.BL3
Alternatively Known As: Wireless Alarm Module, Ajax Alarm Converter, Wired to Wireless Alarm Adapter, Security System Integration Module
Technical Specifications
- Number of zones: 18 wired zones
- Connection types: NC, NO, EOL, 2EOL, 3EOL
- EOL resistance: 1 kΩ to 15 kΩ per resistor, up to 30 kΩ total
- Cable length: up to 400 m with 0.22 mm² copper-clad aluminium conductor
- Operation modes: pulse, bistable
- Event types: 15 event types of wired devices
- Power supply: 100–240 V~, 50/60 Hz
- Backup power supply: 12 V⎓, up to 7 Ah capacity, full charge cycle up to 30 hours
- Connected devices power supply: 10.5–15 V⎓, max 1 A total current
- Power lines: three lines (one for fire detectors, two for other devices)
- Operating temperature: −10 °C to +40 °C
- Operating humidity: up to 75%
- Protection class: IP40, IK06
- Dimensions (H x L x W): 100mm x 192mm x 238mm
- Weight: 0.8 kg
Key Features
- Supports 18 wired zones with NO, NC, EOL, 2EOL, 3EOL connection types
- Rails for fixing backup battery of 4 or 7 Ah capacity
- Three power lines for fire and intrusion detectors
- Wireless connection to hub up to 2000 meters
- Alarm delivery in 0.15 seconds
- Adjustable ping interval from 12 seconds
- Instant detection of connection loss, short circuit, tampering, and power failure
- Equipped with two tampers detecting removal and opening of the device
- Backup battery can power devices for up to 4 days
Professional Installation Requirements
- Installation should be performed by a qualified security system technician or electrician to ensure proper integration and compliance with safety standards.
Applications
- Integration of existing wired alarm systems with Ajax wireless security system
- Security management via mobile app
- Suitable for residential and commercial security upgrades
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Extends the life of existing wired alarm systems, reducing electronic waste
- Enables remote management reducing the need for physical service visits
Warranty Information
24 months warranty.
Available Now
The AJAX MultiTransmitter Black is available for immediate purchase, ideal for upgrading existing wired alarm systems to modern wireless security solutions.
