AJAX MultiTransmitter White | 18 Wired Zones | Instant Alarm Delivery | Backup Battery Support | by Dicker Data
The AJAX MultiTransmitter White is designed to integrate existing wired alarm systems with modern Ajax wireless technology, supporting up to 18 wired zones. Ideal for both residential and commercial applications, it features instant alarm delivery in just 0.15 seconds and a backup battery that can power devices for up to 4 days. With professional installation recommended, this module ensures reliable security management via a mobile app.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: AJAX MultiTransmitter White | 18 Wired Zones | Instant Alarm Delivery | Backup Battery Support | by Dicker Data
Brand: Dicker Data
SKU: 30662.62.WH3
Alternatively Known As: Wireless Alarm Module, Wired Alarm Converter, Ajax Alarm Integration Module, MultiTransmitter Wireless Adapter
Technical Specifications
- Number of zones: 18 wired zones
- Connection types: NC, NO, EOL, 2EOL, 3EOL
- EOL resistance: 1 kΩ to 15 kΩ per resistor, up to 30 kΩ total
- Cable length: up to 400 m with 0.22 mm² copper-clad aluminium conductor
- Operation modes: pulse, bistable
- Event types: 15 event types of wired devices
- Power supply: 100–240 V~, 50/60 Hz
- Backup power supply: 12 V⎓, up to 7 Ah capacity, full charge cycle up to 30 hours
- Connected devices power supply: 10.5–15 V⎓, max 1 A total current
- Power lines: three lines (one for fire detectors, two for other devices)
- Operating temperature: −10 °C to +40 °C
- Operating humidity: up to 75%
- Protection class: IP40, IK06
- Dimensions (H x L x W): 100mm x 192mm x 238mm
- Weight: 0.874 kg
Key Features
- Supports 18 wired zones with NO, NC, EOL, 2EOL, 3EOL connection types
- Rails for fixing backup battery of 4 or 7 Ah capacity
- Three power lines for fire and intrusion detectors
- Connection to Ajax hub up to 2000 meters
- Alarm delivery in 0.15 seconds
- Adjustable ping interval from 12 seconds
- Instant detection of connection loss, short circuit, tampering, and power failure
- Two tampers detect removal of module from surface and opening of lid
- Backup battery can power devices for up to 4 days
Professional Installation Requirements
- Professional installation by a qualified security system technician or electrician is recommended to ensure proper integration and compliance with safety standards.
Applications
- Integration of existing wired alarm systems with Ajax wireless security system
- Security management via mobile app
- Residential and commercial alarm system upgrades
- Remote and on-site system setup and monitoring
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Extends the life of existing wired alarm systems, reducing electronic waste
- Enables remote monitoring and control, potentially reducing unnecessary site visits and energy use
Warranty Information
24 months warranty.
Available Now
The AJAX MultiTransmitter White wireless module is available for immediate purchase, ideal for upgrading existing wired alarm systems to modern wireless security solutions.
