Allen-Bradley 18mm Metal Cylindrical Retroreflective Infrared Sensor
The Allen-Bradley 18mm Metal Cylindrical Retroreflective Infrared Sensor offers reliable object detection with a robust metal housing, suitable for industrial automation applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Allen-Bradley 18mm Metal Cylindrical Retroreflective Infrared Sensor
Brand: Allen-Bradley
SKU: 42CMU1MNBD4
Alternatively Known As: 18mm Metal Proximity Sensor, Retroreflective Infrared Sensor, Cylindrical Photoelectric Sensor
Technical Specifications
- Sensor Type: Retroreflective infrared
- Housing: Metal, 18 mm cylindrical mount
- Output Type: NPN, DC complementary LO/DO
- Connection: 4 pin micro quick disconnect
- Response Time: 2.00 ms
- Minimum Sensing Distance: 3 mm
- Operating Distance: 4000 mm
- Sensing Distance: 3500 mm
- Sensitivity: Not adjustable
- Dimensions (H x L x W): 18mm x 50mm x 18mm
- Weight: 0.2 kg
Key Features
- 18 mm cylindrical metal sensor housing
- Standard retroreflective infrared sensing
- NPN output with DC complementary LO/DO
- 4 pin micro quick disconnect connection
- Not adjustable sensitivity
- Minimum sensing distance of 3 mm
- Operating distance up to 4000 mm
- Fast response time of 2.00 ms
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper wiring and sensor alignment.
Applications
- Industrial automation and control systems
- Object detection in manufacturing lines
- Metal detection in automated processes
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable metal construction reduces replacement frequency and waste
- Energy-efficient infrared sensing technology
Warranty Information
Radwell 2-year warranty included; factory warranty does not apply.
Available Now
The Allen-Bradley 18mm Metal Cylindrical Retroreflective Infrared Sensor is available for immediate purchase, ideal for industrial automation and control applications.
