Allen-Bradley 800TCFXMP16RA7 Illuminated Push Button
The Allen-Bradley 800TCFXMP16RA7 is a durable illuminated push button with a 30.5 mm mushroom head, designed for industrial applications requiring reliable 3-position push-pull control.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Allen-Bradley 800TCFXMP16RA7 Illuminated Push Button
Brand: Allen-Bradley
SKU: 800TCFXMP16RA7
Alternatively Known As: Illuminated Push Button Switch, Mushroom Head Push-Pull Button, 3-Position Push Button
Technical Specifications
- Button Diameter: 30.5 mm
- Operation: 3-position push-pull (momentary-maintained-maintained)
- Illumination: Incandescent transformer, 120V AC 50/60 Hz
- Material: Metal with Type 4/13 terminal guards
- Contact Configuration: 1 Normally Closed, 1 Normally Open
- Dimensions (H x L x W): 35mm x 50mm x 35mm
- Weight: 0.3 kg
Key Features
- 30.5 mm mushroom head push-pull button
- 3-position operation: momentary-maintained-maintained
- Illuminated with incandescent transformer at 120V AC 50/60 Hz
- Metal construction with Type 4/13 guards on terminals
- Standard contact configuration: 1 NCLB 1 NC
Professional Installation Requirements
- Installation by a qualified electrician is recommended to ensure compliance with electrical safety standards.
Applications
- Industrial control panels
- Machinery operation interfaces
- Automation systems requiring push-pull control
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable metal construction reduces replacement frequency and waste
- Energy-efficient incandescent transformer for illumination
Warranty Information
Radwell 2-year warranty included; factory warranty does not apply.
Available Now
The Allen-Bradley 800TCFXMP16RA7 Illuminated Push Button is available for immediate purchase, ideal for industrial and automation control applications.
