Allen-Bradley 800TCFXMQ24RA7 Illuminated Push Button
The Allen-Bradley 800TCFXMQ24RA7 is a durable illuminated push button with a 30.5 mm mushroom head, designed for industrial applications requiring a 3-position push-pull control with metal construction and terminal guards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Allen-Bradley 800TCFXMQ24RA7 Illuminated Push Button
Brand: Allen-Bradley
SKU: 800TCFXMQ24RA7
Alternatively Known As: Illuminated Push Button Switch, Mushroom Head Push-Pull Button, 3-Position Push Button
Technical Specifications
- Button Diameter: 30.5 mm
- Operation: 3-position push-pull (momentary-maintained-maintained)
- Illumination: Incandescent, full voltage 24V AC/DC
- Material: Metal housing
- Terminal Guards: Type 4/13
- Contact Configuration: 1 Normally Closed (NCLB), 1 Normally Closed (NC)
- Color: Red
- Dimensions (H x L x W): 35mm x 50mm x 35mm
- Weight: 0.2 kg
Key Features
- 30.5 mm mushroom head push-pull design
- 3-position operation: momentary-maintained-maintained
- Illuminated with incandescent full voltage 24V AC/DC
- Metal construction with Type 4/13 guards on terminals
- Standard contact configuration: 1 NCLB 1 NC
Professional Installation Requirements
- Installation by a qualified electrician is recommended to ensure compliance with electrical safety standards and proper wiring.
Applications
- Industrial control panels
- Machinery operation interfaces
- Automation systems requiring push-pull control
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable metal construction reduces replacement frequency and waste
- Low power incandescent illumination for efficient operation
Warranty Information
Radwell 2-year warranty included; factory warranty does not apply.
Available Now
The Allen-Bradley 800TCFXMQ24RA7 Illuminated Push Button is available for immediate purchase, ideal for industrial and automation control applications.
