Allen-Bradley 800TCFXTQ24XD4 Illuminated Push Button
The Allen-Bradley 800TCFXTQ24XD4 is a durable illuminated push button with a 2-position push-pull mushroom head, designed for industrial applications requiring reliable control and safety.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Allen-Bradley 800TCFXTQ24XD4 Illuminated Push Button
Brand: Allen-Bradley
SKU: 800TCFXTQ24XD4
Alternatively Known As: Illuminated Push Button Switch, Mushroom Head Push Button, Push-Pull Control Button
Technical Specifications
- Type: Push Button
- Operation: 2-position push-pull
- Head Style: Mushroom head (push-pull)
- Illumination: Incandescent
- Voltage: Full voltage - 24V AC/DC
- Protection: Type 4/13
- Terminal Guards: Included
- No Cap: Standard - 1 NCLB
- Dimensions (H x L x W): 35mm x 50mm x 35mm
- Weight: 0.3 kg
Key Features
- 2-position push-pull operation
- Illuminated mushroom head for clear visibility
- Metal construction with Type 4/13 protection
- Guards on terminals for safety
- Push-pull/twist mechanism
- Incandescent illumination
- Full voltage operation at 24V AC/DC
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical safety standards.
Applications
- Industrial control panels
- Machinery operation
- Emergency stop and start functions
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Long-lasting incandescent illumination reduces frequent replacements
- Robust metal construction minimizes waste through durability
Warranty Information
Radwell 2-year warranty included; factory warranty does not apply.
Available Now
The Allen-Bradley 800TCFXTQ24XD4 Illuminated Push Button is available for immediate purchase, ideal for industrial and commercial control panel applications.
